The Wacker Neuson Pipe Guide is a genuine OEM component designed for the DPU 4045, DPU 4545, DPU 5045, DPU 5545, DPU 6055, and DPU 6555 series reversible vibratory plate compactors. As a direct OEM replacement, part is sourced and manufactured to the same specifications as the original, ensuring a correct fit within the exciter and hydraulic steering assembly of these heavy-duty diesel compactors. This part is compatible across a wide range of DPU variants including H, He, Heh, Hec, Heap, and Y-series configurations. Verify your machine's model and serial number before ordering to confirm fitment.
Key Features
- Genuine OEM Construction: — Manufactured to the same dimensional and material tolerances as the original part, ensuring the guide tube maintains proper alignment within the compactor's exciter or hydraulic column without play or misalignment.
- Direct OEM Replacement: — Part number 5000103880 installs into the same position as the factory component, requiring no modification to surrounding hardware or mounting points.
- Broad DPU Series Compatibility: — Fits DPU 4045, DPU 4545, DPU 5045, DPU 5545, DPU 6055, and DPU 6555 reversible vibratory plate compactors across multiple variant suffixes, covering a wide range of diesel-powered compaction machines.
- Exciter Assembly Integrity: — A correctly fitted pipe guide keeps internal components properly aligned under the high-vibration loads these machines generate; a worn or damaged guide can allow lateral movement that accelerates wear on adjacent parts.
- Long-Term Fit for Demanding Conditions: — Reversible plate compactors operate under continuous vibration in demanding soil and aggregate environments; using a genuine OEM guide ensures the assembly holds its geometry through extended service cycles.
The pipe guide is a precision-fit component within the exciter or hydraulic steering column assembly of a reversible vibratory plate compactor. Its role is to constrain and channel internal components — such as rods or pistons — along a defined path, preventing lateral movement under the intense vibration these machines produce during compaction work. When the pipe guide wears, cracks, or becomes misaligned, it can allow unwanted movement in the assembly, leading to accelerated wear on surrounding parts, loss of directional control response, and potential damage to the exciter housing.
Part Details
| Part Number | 5000103880 |
|---|---|
| Old Part Number | 0103880 |
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Pipe Guide |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| V.Plate DPU 5045Heap | DPU 5045H | 5000610046, 5000610052, 5000610047, 5000007862, 5000007936, 5000007965, 5000610045 |
| V.Plate DPU 4045Hap | DPU 4045H | 5000610044, 5000610051, 5000610064, 5000007888, 5000007935, 5000610043 |
| DPU6555Heh | DPU6555Heh | 5100009636 |
| DPU6555HEH US | DPU6555Heh US | 5100009637 |
| DPU6555Hehap | DPU6555Hehap | 5100009638 |
| DPU6555 Hech | DPU6555 Hech | 5100009639 |
| DPU6555Hech US | DPU6555Hech US | 5100009650 |
| V.Plate DPU 6055Heap | DPU 6055 | 5000610049, 5000610050, 5000008766, 5000008767, 5000008768, 5000610048 |
| DPU6055-VIBROPLATE | DPU 6055He | 5000610053 |
| DPU5545Heh | DPU5545Heh | 5100009652 |
| DPU5545HEH US | DPU5545Heh US | 5100009653 |
| DPU5545Hehap | DPU5545Hehap | 5100009654 |
| DPU5545Hech | DPU5545Hech | 5100009655, 5100051523 |
| DPU4545Heh | DPU4545Heh | 5100009659 |
| DPU4545HEH US | DPU4545Heh US | 5100009660 |
| DPU6555Hesh | DPU6555Hesh | 5100015774 |
| DPU6555Hecsh | DPU6555Hecsh | 5100015775 |
| DPU6555He | DPU6555He | 5100016940 |
| DPU6555Hes | DPU6555Hes | 5100016941 |
| DPU6555Heap | DPU6555Heap | 5100016943 |
| DPU6555Hec | DPU6555Hec | 5100016944 |
| DPU6555Hecs | DPU6555Hecs | 5100016945 |
| DPU 6555H | DPU 6555H | 5100009651, 5000610355 |
| DPU4545Hech | DPU4545Hech | 5100015429, 5100051522 |
| DPU 6555Hs | DPU 6555Hs | 5100015773 |
| DPU5545He | DPU5545He | 5100016947 |
| DPU5545Heap | DPU5545Heap | 5100016949 |
| DPU5545Hec | DPU5545Hec | 5100016950 |
| DPU4545He | DPU4545He | 5100016951 |
| DPU4545Hec | DPU4545Hec | 5100016953 |
| DPU5545H | DPU 5545H | 5100009656, 5000610352 |
| DPU4545H | DPU 4545H | 5100009661, 5000610348 |
| DPU5545HECH US | DPU5545Hech US | 5100016948 |
| DPU4545HECH US | DPU4545Hech US | 5100016952 |
| DPU6555Hechzf | DPU6555Hechzf | 5100021400 |
| vibration plate DPU 4045Y | DPU 4045Y | 5000610027 |
| DPU6055-VIBROPLATE | DPU 6055 WC | 5000610175 |
| DPU4545Hechzf | DPU4545Hechzf | 5100022112 |
| DPU45Yeh US | DPU45Yeh US | 5100063121 |
| V.Plate DPU 4045Ye | DPU 4045YE | 5000610181 |
| Vibratory Plate DPU 6555Heap | DPU 6555Heap | 5000610356 |
| DPU4045Yeh | DPU4045Yeh | 5100009662 |
| Vibration Plate | DPU6555He US | 5100016942 |
| Vibration Plate | DPU6555Hec US | 5100016946 |
| DPU4045Yeh LRC | DPU4045Yeh LRC | 5100063118 |
| DPU40Yeh US | DPU40Yeh US | 5100063124 |
| DPU40Yeh EU | DPU40Yeh EU | 5100068379 |
| DPU45Yeh EU | DPU45Yeh EU | 5100068380 |
| Vibratory Plate DPU 4045Ye | DPU 4045Ye | 5000610350 |
| Vibratory Plate DPU 6555He | DPU 6555He | 5000610354 |
| DPU 5045He-VIBROPLATE | DPU 5045He US | 5000610367 |
| DPU5545He-VIBROPLATE | DPU 5545He US | 5000610402 |
| Vibratory Plate DPU 4545He US | DPU 4545He US | 5100000679 |
| DPU4045YE | DPU4045Ye | 5100016954 |
| DPU6555Hech | DPU6555Hech | 5100051524 |
| DPU4545He-VIBROPLATE | DPU 4545He | 5000610347 |
| Vibratory Plate DPU 4545Hap | DPU 4545Hap | 5000610349 |
| Vibratory Plate DPU 5545He | DPU 5545He | 5000610351 |
| Vibratory Plate DPU 5545Heap | DPU 5545Heap | 5000610353 |
| Vibratory Plate | DPU 6555Hec | 5100004060 |
| DPU6555Hec Reversible Vibratory Plate | DPU 6555Hec US | 5100004399 |
| Vibratory Plate | DPU 5545Hec | 5100005859 |
| DPU4045Yeh EU | DPU4045Yeh EU | 5100063123 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
