The Wacker Neuson is a genuine OEM Angle Strut 22-3/8 R.H. Side designed for the HP, HPG, HC, and HE series vibratory truss screeds. Sourced directly from Wacker Neuson, this part is manufactured to the same standards as the original component installed at the factory, ensuring a correct and consistent fit on affected screed sections. It is compatible across a wide range of models including the HP50, HP100, HPG50, HPG100, HC50, HC100, HE50, and HE100 series. Whether you are servicing a power section or a screed extension, part number is the correct right-hand side angle strut for these applications.
Key Features
- Genuine OEM Structural Integrity — Manufactured to original Wacker Neuson specifications, maintaining the correct geometry and load-bearing capacity required for truss screed frame performance.
- Right-Hand Side Specific — Designed exclusively for the R.H. side of the screed frame assembly; correct orientation is critical for proper structural alignment and screed operation.
- Broad Series Compatibility — Fits HP50, HP100, HPG50, HPG100, HC50, HC100, HE50, and HE100 vibratory truss screed models, covering both power sections and screed sections.
- Maintains Screed Frame Alignment — A correctly fitted angle strut keeps the screed frame square and level, which directly affects surface finish consistency across the full screed width.
- Direct OEM Replacement — Replaces the original 5000117586 angle strut with no modifications to existing mounting points or hardware on supported models.
The angle strut is a structural frame member that supports the lateral rigidity and alignment of the vibratory truss screed assembly. It holds the screed sections in the correct angular position relative to the frame, which is essential for achieving a flat, consistent concrete surface finish. When an angle strut is bent, cracked, or worn at its mounting points, the screed frame can rack or twist, leading to uneven screeding, surface defects, and increased wear on adjacent components.
Part Details
| Part Number | 5000117586 |
|---|---|
| Old Part Number | 0117586 |
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Angle Strut 22-3/8 R.H. Side |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| HPG100A | HPG100A | 5000009507 |
| HP50A | HP50A | 5000009508 |
| Vibratory Truss Screed, Power Section | HP100A | 5000009506 |
| HPG50A | HPG50A | 5000009509 |
| HE100 | HE100 | 5000130384, 5000115711 |
| HC50 | HC50 | 5000130377, 5000115709 |
| HC100 | HC100 | 5000130378, 5000115708 |
| HE50 | HE50 | 5000130383, 5000115712 |
| Vibratory Truss Screed, Power Section | HP100 | 5000008291 |
| Vibratory Truss Screed, Power Section | HP50 | 5000008292 |
| Vibratory Truss Screed, Power Section | HPG100 | 5000008293 |
| Vibratory Truss Screed, Power Section | HPG50 | 5000008294 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
