The Wacker Neuson Banjo Bolt is a genuine OEM component designed for the DPU 9070 and DPU 100-70 reversible vibratory plate compactors. Sourced directly from Wacker Neuson, this banjo bolt matches the exact specifications of the original part installed at the factory. It is confirmed compatible with the DPU 9070 and the DPU 100-70 (100kN, 70cm/28in) reversible plate compactor models. Using the correct OEM replacement ensures the hydraulic or fluid circuit connection maintains its designed integrity without the risk of improper sealing or fitment issues that can arise from non-matched hardware.
Key Features
- Genuine OEM Construction — Manufactured to Wacker Neuson's original thread pitch, shank diameter, and hollow-bore specification, ensuring the banjo fitting seats and seals exactly as intended.
- Direct-Fit Replacement — Drops into the existing banjo fitting connection on the DPU 9070 and DPU 100-70 without rework, using the same bolt geometry as the original.
- Confirmed DPU Fitment — Verified for the DPU 9070 and DPU 100-70 reversible vibratory plate compactor series, covering both machine configurations in the fitment data.
- Leak-Free Fluid Circuit Integrity — A correctly torqued banjo bolt prevents fluid seepage at the connection point, keeping the compactor's hydraulic or lubrication circuit operating at the proper pressure and flow rate.
- Fuel and Hydraulic System Safety — Banjo bolts are critical fasteners in pressurized fluid lines; using the correct OEM part with the proper thread engagement reduces the risk of connection failure under operating load.
A banjo bolt is a hollow fastener that passes through the center of a banjo fitting to allow fluid — hydraulic oil or fuel — to flow through the bolt itself into the connected line or component. It forms the central clamping point of the banjo assembly, compressing the sealing washers on either side of the fitting to create a leak-free joint under system pressure. If a banjo bolt is cross-threaded, over-torqued, or replaced with an incorrect part, the joint can weep fluid or fail outright, disrupting pressure to the connected circuit and potentially causing the machine to operate erratically or stop functioning.
Part Details
| Part Number | 5000203349 |
|---|---|
| Old Part Number | 0203349 |
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Banjo Bolt |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Vibration Plate DPU 9070 | DPU 9070 | 5000007941 |
| Reversible Vibratory Plate, 10 0kN, 70cm/28in | DPU 100-70 | 5000007942 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
