The Bomag 05800626 Cradle is a genuine OEM replacement built for a wide range of Bomag BW-series tandem rollers and single drum rollers, including the BW 174 AD, BW 184 AD, BW 202 AD-4, BW 190 AD-4, BW 203 AD-4, and many additional BW-series variants. Sourced directly from Bomag, this cradle meets the same specifications as the original component installed at the factory. This part is a direct replacement for the original, ensuring it seats and connects correctly without any modifications. Contractors and equipment technicians can order with confidence knowing this cradle is the right component for the machines listed.
Key Features
- Genuine OEM Construction — manufactured to Bomag's original design tolerances, ensuring the cradle maintains proper load distribution and structural alignment within the roller assembly
- Direct Drop-In Replacement — engineered to the same dimensions and mounting interface as the original, so this part installs into the machine without rework or adaptation
- Broad BW-Series Fitment — compatible with an extensive range of Bomag tandem rollers and single drum rollers, including the BW 174 AD, BW 174 AP-4, BW 184 AD, BW 184 AD-2, BW 161 AD-4, BW 202 AD-4, BW 203 AD-4, BW 190 AD-4, BW 212 D-3, BW 177 DH-4, BW 145 D-3, and additional BW-series models
- Structural Integrity Restored — a worn or damaged cradle can allow critical components to shift under load, leading to vibration irregularities and accelerated wear; replacing it restores proper support and stability
- Verified Part Number Fit — order by Bomag part number 05800626 to confirm you are receiving the correct cradle for your specific roller configuration
The cradle is a structural mounting component that supports and positions key assemblies within the roller's drivetrain or vibration system, holding them securely in place during operation. By maintaining correct alignment and absorbing operational stresses, the cradle ensures that connected components function as intended and wear evenly over time. When a cradle cracks, deforms, or wears beyond tolerance, it can cause misalignment, abnormal vibration, and premature failure of surrounding parts — making timely replacement essential to keeping the roller performing at its best.
Part Details
| Part Number | 05800626 |
|---|---|
| Brand | Bomag |
| Part Type | Genuine OEM |
| Description | Cradle |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Tandem Roller | BW 184 AD | 00810713, 00810715, 00817514 |
| Single Drum Roller | BW 212 D-3 | 00815325, 00815326 |
| Tandem Roller | BW 131 ACW-2 | 00817468 |
| Tandem Roller | BW 131 AD-2 | 00817469 |
| Single Drum Roller | BW 145 D-3 | 00817479, 00817637 |
| Tandem Roller | BW 170 AD | 00817498 |
| Tandem Roller | BW 174 AC | 00817499 |
| Tandem Roller | BW 174 AC AM | 00817500 |
| Tandem Roller | BW 174 AD | 00817501 |
| Tandem Roller | BW 174 AD AM | 00817502 |
| Tandem Roller | BW 180 AD | 00817513 |
| Single Drum Roller | BW211D 3 | 00817520, 00817581, 00817649 |
| Single Drum Roller | BW212D 3 | 00817521 |
| Single Drum Roller | BW145D 3 | 00817576, 00817927 |
| Tandem Roller | BW 184 AD-2 AM | 00817600 |
| Tandem Roller | BW 161 AD-4 | 00817641, 00818481, 00818959, 00824003, 00824735 |
| Tandem Roller | BW 202 AD-4 | 00817642, 00818381, 00818961, 00824005 |
| Tandem Roller | BW 174 AD-2 AM | 00817693 |
| Tandem Roller | BW 174 AD-2 | 00817695 |
| Tandem Roller | BW 141 AD-4 | 00817697, 00818561, 00818955, 00818999 |
| Tandem Roller | BW 154 AD-4 AM | 00817699, 00818447 |
| Tandem Roller | BW 174 AC-2 | 00817712 |
| Tandem Roller | BW 174 AC-2 AM | 00817714 |
| Tandem Roller | BW 170 AD-2 AM | 00817716 |
| Tandem Roller | BW 161 ADH-4 | 00817739 |
| Single Drum Roller | BW 177 DH-4 | 00817761, 00817765, 00818453, 00818543, 00824037, 00824133 |
| Single Drum Roller | BW 177 PDH-4 | 00817763, 00818541 |
| Single Drum Roller | BW 179 DH-4 | 00817767, 00818545, 00824137 |
| Single Drum Roller | BW 179 PDH-4 | 00817769, 00818549, 00824139 |
| Tandem Roller | BW 190 AD-4 | 00817823, 00818379, 00818965, 00824009 |
| Tandem Roller | BW 190 AD-4 AM | 00817825, 00818309, 00824021 |
| Tandem Roller | BW 203 AD-4 AM | 00817837, 00818591, 00824019, 00825067 |
| Tandem Roller | BW 184 AD-2 | 00817841 |
| Tandem Roller | BW151AD 4 | 00817843 |
| Tandem Roller | BW 154 AD-4 | 00817901, 00818557 |
| Single Drum Roller | BW 212 D-30 | 00817907 |
| Tandem Roller | BW 151 AD-4 AM | 00817913, 00818555, 00824017 |
| Tandem Roller | BW 141 AD-4 AM | 00817925, 00818553 |
| Tandem Roller | BW 161 AC-4 | 00817947, 00818589, 00818967 |
| Tandem Roller | BW 151 AC-4 AM | 00817953, 00818559, 00824025 |
| Tandem Roller | BW 154 AP-4 | 00818301, 00824179, 00824717 |
| Tandem Roller | BW 154 ACP-4 AM | 00818303 |
| Tandem Roller | BW 154 ACP-4 | 00818305, 00824721 |
| Single Drum Roller | BW145DH 40 | 00818323 |
| Tandem Roller | BW 174 AP-AM | 00818343, 00818537 |
| Tandem Roller | BW 174 ACP-AM | 00818355, 00818535 |
| Tandem Roller | BW 161 ADH-4 CHINA | 00818365 |
| Tandem Roller | BW 174 AP | 00818395, 00818517 |
| Tandem Roller | BW 170 AP AM | 00818515 |
| Tandem Roller | BW 174 ACP | 00818519 |
| Tandem Roller | BW 151 AD-4 | 00818563, 00818957, 00824001 |
| Tandem Roller | BW 151 AC-4 | 00818565, 00819699, 00824011 |
| Tandem Roller | BW 203 AD-4 | 00818599, 00818963 |
| Tandem Roller | BW 174 AP-4 AM | 00818655, 00818845, 00824543 |
| Single Drum Roller | BW145D 40 | 00818935, 00818937 |
| Tandem Roller | BW 174 AP-4 AM PB | 00818971 |
| Tandem Roller | BW 174 AP-4 PB | 00818973 |
| Tandem Roller | BW 174 AP-4i AM | 00824093, 00824627, 00825051 |
| Tandem Roller | BW 174 AP-4i | 00824095, 00824629 |
| Tandem Roller | BW 161 ADO-4 | 00824333, 00824335 |
| Tandem Roller | BW 161 AD-4 EU-Flex | 00824393 |
| Tandem Roller | BW 202 AD-4 EU-Flex | 00824395 |
| Tandem Roller | BW 203 AD-4 AM EU-Flex | 00824397 |
| Tandem Roller | BW 174 AP-4 | 00824545 |
| Tandem Roller | BW 154 AP-4i | 00824587 |
| Tandem Roller | BW 154 ACP-4i AM | 00824589 |
| Tandem Roller | BW 154 AP-4 AM | 00824715 |
| Tandem Roller | BW203AD-4 | 00824739, 00826243 |
| Tandem Roller | BW 205 AD 4 | 00824889 |
| Tandem Roller | BW 203 ADO-4 | 00825049 |
| Tandem Roller | BW 174 APO-4i | 00825099 |
| Tandem Roller | BW 174 ACP 4I AM | 00825103 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
