The Bomag 05748328 Ratchet Guide is a genuine OEM component designed for a wide range of Bomag vibratory plates and walk-behind rollers, including BP-series vibratory plates such as the BP 8/34, BP 10/35, BP 20/48, and BP 25/50, reversible vibratory plates including the BPR 25/40, BPR 25/50, BPR 35/60 H, and BPR 25/45-3, BVP-series vibratory plates, and the BW 55 E walk-behind roller. As a genuine OEM part, this Ratchet Guide is manufactured to the same specifications as the original, ensuring a correct, direct fit with no guesswork. Sourced directly from Bomag, part number 05748328 is the right choice when an accurate replacement matters for keeping your compactor operating as intended.
Key Features
- Genuine OEM Precision — Manufactured to Bomag's exact dimensional and material specifications, ensuring the ratchet mechanism engages and releases with the correct resistance and travel every time.
- Direct Drop-In Replacement — Engineered to match the original mounting points and geometry, this Ratchet Guide installs directly without modification or adjustment.
- Broad Fitment Coverage — Compatible with BP, BPR, and BVP vibratory plate families — including models such as the BP 20/48, BP 25/50, BPR 25/40, BPR 35/60 H, and BVP 18/45 — as well as the BW 55 E walk-behind roller.
- Ratchet Mechanism Integrity — A worn or damaged guide causes imprecise ratchet engagement, leading to inconsistent throttle or control response; replacing it restores positive, repeatable operation.
- Verified Part Number — Order with confidence: part number 05748328 is traceable to Bomag's OEM catalog, eliminating the risk of receiving an incompatible component.
The Ratchet Guide channels and supports the ratchet assembly's movement within the control mechanism, maintaining proper alignment so the ratchet teeth engage cleanly and hold their position under operating load. When this guide wears or cracks, the ratchet can slip, bind, or fail to lock, resulting in unreliable throttle or speed control on the plate compactor or roller. Replacing a faulty Ratchet Guide with a genuine Bomag part restores predictable, secure control response and protects the surrounding ratchet components from accelerated wear.
Part Details
| Part Number | 05748328 |
|---|---|
| Brand | Bomag |
| Part Type | Genuine OEM |
| Description | Ratchet Guide |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Vibratory Plate | BP 10/36-2 | 00812064, 00817411, 00817609, 00818605 |
| Vibratory Plate | BP 15/36-2 | 00817412 |
| Vibratory Plate | BP 18/45-2 | 00817420, 00817905, 00818449, 00818603 |
| Vibratory Plate | BP 20/48 | 00817421 |
| Vibratory Plate | BP 23/48 | 00817423 |
| Vibratory Plate | BP 25/48 | 00817426 |
| Vibratory Plate | BP 8/34 | 00817429, 00818307 |
| Reversible Vibratory Plate | BPR 25/40 | 00817432, 00818399, 00824077, 00824303 |
| Reversible Vibratory Plate | BPR 30/38-3 BPR 35/38-3 | 00817434 |
| Walk-Behind / Light Roller | BW 55 E | 00817553, 00824061, 00825111 |
| Reversible Vibratory Plate | BPR 25/45-3 | 00817646 |
| Reversible Vibratory Plate | BPR 35/60 H | 00818093, 00824075, 00824315 |
| Vibratory Plate | BP 12/50 A | 00818387, 00818639, 00824067, 00824593, 00824887, 00825027, 00825503 |
| Reversible Vibratory Plate | BPR 25/50 | 00818401, 00824079, 00824307 |
| Vibratory Plate | BP 10/35 | 00818633, 00824063, 00824607, 00825021 |
| Vibratory Plate | BP 12/40 | 00818635, 00824065, 00824609, 00825025 |
| Vibratory Plate | BP 20/50 | 00818641, 00824069, 00824595, 00825499, 00825023 |
| Vibratory Plate | BP 25/50 | 00818647, 00824071, 00824597, 00825029, 00825505 |
| Vibratory Plate | BVP 10/36 | 00818687, 00824083, 00824611, 00825315 |
| Vibratory Plate | BVP 18/45 | 00818689, 00824081, 00824365, 00824613, 00825249, 00825321, 00825603 |
| Vibratory Plate | BVP 12/50 A | 00825145, 00825317 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
