The Bomag 06245052 Guiding Band is a genuine OEM component designed for Bomag BPR-series and BPH-series reversible vibratory plates, covering a wide range of models including the BPR 25/40, BPR 35/60 D, BPR 55/65 D, BPR 65/70 D, BPR 100/80 D, and BPH 80/65, among others. As a factory-sourced part, this guiding band matches the original material grade and dimensional tolerances specified for your machine. This part is a direct OEM replacement, so it installs into the existing assembly without modification, restoring correct mechanical guidance to the compaction system. Verify your model against the fitment list to confirm compatibility before ordering.
Key Features
- Genuine OEM Material Match — sourced directly from Bomag, this guiding band meets the exact material grade and dimensional tolerances of the original, ensuring consistent wear characteristics and service life appropriate for reversible vibratory plate applications
- Direct-Fit Replacement — engineered to the same profile as the factory part, this component seats correctly within the existing assembly on BPR and BPH reversible vibratory plates without rework or adaptation
- Broad BPR and BPH Coverage — fits an extensive range of Bomag reversible vibratory plates including the BPR 25/40, BPR 25/50, BPR 35/42, BPR 35/60, BPR 40/45 D-3, BPR 45/55, BPR 50/55 D, BPR 55/65 D, BPR 60/65, BPR 65/70 D, BPR 70/70 D, BPR 100/80 D, and BPH 80/65, among others
- Restored Compaction Accuracy — a worn or damaged guiding band allows unwanted lateral movement in the drive or exciter assembly, degrading compaction quality and accelerating wear on surrounding components; replacing it promptly keeps the plate tracking and compacting correctly
- Verified Part Number Traceability — ordering by Bomag part number 06245052 ensures you receive the correct guiding band for your specific BPR or BPH model, eliminating the guesswork of cross-referencing aftermarket catalogs
The guiding band controls the lateral positioning of a moving component within the exciter or drive assembly of a reversible vibratory plate compactor, keeping internal parts aligned during operation. By maintaining this alignment, it prevents side-to-side play that would otherwise cause uneven wear on shafts, bearings, and housings, and reduce the compaction force delivered to the ground. When the guiding band wears through or deforms, operators typically notice increased vibration, irregular plate movement, or accelerated deterioration of adjacent components — all signs that the band needs replacement before further damage occurs.
Part Details
| Part Number | 06245052 |
|---|---|
| Brand | Bomag |
| Part Type | Genuine OEM |
| Description | Guiding Band |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Reversible Vibratory Plate | BPR 30/38-3 BPR 35/38-3 | 00817434 |
| Reversible Vibratory Plate | BPR30 /38 | 00817435 |
| Reversible Vibratory Plate | BPR55 | 00817440 |
| Reversible Vibratory Plate | BPR 30/38 D-3 | 00817707, 00817709, 00817436 |
| Reversible Vibratory Plate | BPR 65/70 D | 00817869, 00817993, 00818567 |
| Reversible Vibratory Plate | BPR45 /55D | 00817903 |
| Reversible Vibratory Plate | BPR 55/65 D | 00817915, 00817985, 00817987, 00817989, 00818495, 00818497, 00818767, 00824249, 00824325, 00825009, 00825537, 00825787, 00826681, 00817923, 00817983 |
| Reversible Vibratory Plate | BPR 45/55 | 00817919, 00818501, 00818503, 00817917 |
| Reversible Vibratory Plate | BPR 45 55 D | 00817921 |
| Reversible Vibratory Plate | BPR 100/80 D | 00817965, 00824253, 00824331, 00824379, 00825143, 00825553, 00825793, 00825795, 00826743, 00826745, 00825549 |
| Reversible Vibratory Plate | BPR 45/55 D | 00817975, 00817977, 00817979, 00817981, 00818491, 00818493, 00818765, 00824247, 00824321, 00824375, 00825007, 00825015, 00825535, 00825803, 00826679 |
| Reversible Vibratory Plate | BPR 35/42 D | 00818085, 00818087, 00818483, 00818485, 00818757, 00818759, 00824311, 00824313, 00824767, 00824771, 00825531, 00825805, 00825807, 00826513, 00826515, 00827469, 00827463 |
| Reversible Vibratory Plate | BPR 35/60 D | 00818089, 00818091, 00818487, 00818489, 00818761, 00818763, 00824243, 00824317, 00824319, 00824371, 00824373, 00824769, 00824773, 00824793, 00825529, 00825533, 00825783, 00825785, 00826517, 00826519, 00827471, 00827465 |
| Reversible Vibratory Plate | BPR 35/60 H | 00818093, 00824075, 00824315, 00825521 |
| Reversible Vibratory Plate | BPR 25/40 | 00818399, 00824077, 00824303, 00825517, 00825817, 00827149 |
| Reversible Vibratory Plate | BPR 25/50 | 00818401, 00824079, 00824307, 00825519, 00825791, 00827153 |
| Reversible Vibratory Plate | BPR 25/40 D | 00818403, 00818753, 00824241, 00824305, 00824369, 00824763, 00824789, 00825523, 00825813, 00826509, 00827313 |
| Reversible Vibratory Plate | BPR 70/70 D | 00818747, 00824251, 00824329, 00824377, 00825117, 00825141, 00825547, 00825551, 00825557, 00825797, 00825799, 00826339, 00826737, 00826739, 00826741 |
| Reversible Vibratory Plate | BPR 25/50 D | 00818755, 00824309, 00824765, 00825525, 00825781, 00826511, 00827315, 00818405 |
| Reversible Vibratory Plate | BPR 50/55 D | 00824323, 00824381, 00824775, 00824779, 00825011, 00825017, 00825245, 00825539, 00825801, 00826335, 00826477, 00826819, 00826835, 00826845 |
| Reversible Vibratory Plate | BPR 60/65 D | 00824327, 00824383, 00824777, 00824781, 00825013, 00825019, 00825247, 00825541, 00825789, 00826337, 00826475, 00826821, 00826837, 00826847 |
| Reversible Vibratory Plate | BPR 40/60 D | 00824895, 00824897, 00825543, 00825809, 00825811, 00826521, 00826523, 00827473, 00827467 |
| Reversible Vibratory Plate | BPR 35/60 | 00825815, 00827157 |
| Reversible Vibratory Plate | BPR 60/65 | 00826045, 00826101, 00826309, 00826993, 00827331 |
| Reversible Vibratory Plate | BPR 35/42 | 00826397 |
| Reversible Vibratory Plate | BPR 45/45 | 00826547, 00826991 |
| Reversible Vibratory Plate | BPR 35/60 e | 00827845 |
| Reversible Vibratory Plate | BPH 80/65 | 00810107, 00817430 |
| Reversible Vibratory Plate | BPR 35/42 D/H | 00825527 |
| Reversible Vibratory Plate | BPR 35/60 D/H | 00824791 |
| Reversible Vibratory Plate | BPR 40/45 D-3 | 00817439 |
| Reversible Vibratory Plate | BPR 40/60 D/E | 00825545 |
| Reversible Vibratory Plate | BPR 50/52 D-3 | 00811426, 00817441 |
