The Bomag 69070144 Insulating Mat is a genuine OEM component designed for BPR-series reversible vibratory plates, including the BPR 35/42 D, BPR 35/60 D, BPR 40/60 D, BPR 40/60 D/E, BPR 45/55, BPR 45/55 D, BPR 50/55 D, BPR 55/65 D, BPR 60/65, and BPR 60/65 D. As a factory-sourced part, it meets the exact material and dimensional specifications Bomag set for these machines. This insulating mat installs directly in position without alteration, ensuring consistent protection and a correct, lasting fit across the full BPR reversible vibratory plate range covered by part number 69070144.
Key Features
- Genuine OEM Material Integrity — sourced directly from Bomag, this insulating mat is produced to the same material grade and thickness specification as the original, ensuring the thermal and vibration isolation it provides is not compromised by substitution
- Direct-Fit Replacement — engineered to match the original mounting profile exactly, this mat drops into position on supported BPR models without trimming, shimming, or rework
- Broad BPR-Series Coverage — fits a wide range of Bomag reversible vibratory plates including the BPR 35/42 D, BPR 45/55 D, BPR 50/55 D, BPR 55/65 D, BPR 60/65 D, and additional BPR variants
- Isolation Where It Counts — a correctly functioning insulating mat buffers heat and vibration transfer between components, protecting surrounding parts from accelerated wear and keeping operating temperatures in check
- OEM Part Number Assurance — ordering by part number 69070144 confirms you are receiving the correct Bomag-specified component, eliminating fitment guesswork on your BPR reversible vibratory plate
An insulating mat serves as a barrier between adjacent components, blocking the transfer of heat, vibration, or electrical energy depending on its location within the machine. On Bomag BPR reversible vibratory plates, this type of mat protects sensitive components from the intense vibration and operational heat these machines generate during compaction work. When the mat deteriorates, cracks, or is missing entirely, the components it shields are exposed to elevated stress levels that can lead to premature failure and unplanned service intervals.
Part Details
| Part Number | 69070144 |
|---|---|
| Brand | Bomag |
| Part Type | Genuine OEM |
| Description | Insulating Mat |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Reversible Vibratory Plate | BPR45 /55D | 00817903 |
| Reversible Vibratory Plate | BPR 55/65 D | 00817915, 00817987, 00817989, 00818497, 00818767, 00824249, 00824325, 00825009, 00825537, 00825787, 00826681 |
| Reversible Vibratory Plate | BPR 45/55 | 00817919, 00818501 |
| Reversible Vibratory Plate | BPR 45/55 D | 00817979, 00817981, 00818493, 00818765, 00824247, 00824321, 00824375, 00825007, 00825015, 00825535, 00825803, 00826679 |
| Reversible Vibratory Plate | BPR 35/42 D | 00818087, 00818485, 00818759, 00824313, 00824771, 00825531, 00825807, 00826515, 00827469 |
| Reversible Vibratory Plate | BPR 35/60 D | 00818091, 00818489, 00818763, 00824319, 00824373, 00824773, 00824793, 00825533, 00825785, 00826519, 00827471 |
| Reversible Vibratory Plate | BPR 50/55 D | 00824323, 00824381, 00824775, 00824779, 00825011, 00825017, 00825245, 00825539, 00825801, 00826335, 00826477, 00826819, 00826835, 00826845 |
| Reversible Vibratory Plate | BPR 60/65 D | 00824327, 00824383, 00824777, 00824781, 00825013, 00825019, 00825247, 00825541, 00825789, 00826337, 00826475, 00826821, 00826837, 00826847 |
| Reversible Vibratory Plate | BPR 40/60 D | 00824897, 00825811, 00826523, 00827473 |
| Reversible Vibratory Plate | BPR 60/65 | 00826045, 00826101, 00826309, 00826993 |
| Reversible Vibratory Plate | BPR 40/60 D/E | 00825545 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
