The Bomag 38010347 Jack Latch is a genuine OEM replacement designed for BW 24 R and C 560 B pneumatic tyred rollers. Sourced directly from Bomag, this part delivers an exact fit with no guesswork — ensuring the jack mechanism operates as intended on your machine. Compatible with both BW 24 R and C 560 B pneumatic tyred rollers, this component is the correct replacement when the original latch shows wear or fails to hold securely.
Key Features
- Genuine OEM Construction — manufactured to Bomag's original design tolerances, ensuring the latch engages and retains the jack with the same positive action as the part it replaces
- Direct Drop-In Replacement — matches the original mounting points and geometry of the jack assembly, so installation is straightforward without machining or modification
- Confirmed Fitment — verified for BW 24 R and C 560 B pneumatic tyred rollers, taking the uncertainty out of ordering the correct latch for your machine
- Secure Retention Under Load — a properly functioning jack latch keeps the jack locked in position during operation and transport, preventing unintended movement that could interrupt the job or damage surrounding components
- Operational Safety — a worn or broken latch can allow the jack to shift unexpectedly during lifting or transport; replacing it promptly with the correct OEM part maintains safe machine handling
The jack latch is a small but critical retention component in the jack assembly of pneumatic tyred rollers. Its job is to hold the jack securely in the raised or stowed position, preventing it from dropping or shifting while the machine is in use or being moved between sites. When the latch wears, cracks, or loses its holding ability, the jack can become unstable — creating both a handling hazard and the risk of mechanical damage to the surrounding assembly. Replacing a failed latch promptly with a genuine OEM part, such as part number 38010347, restores the positive locking action the system was designed to deliver.
Part Details
| Part Number | 38010347 |
|---|---|
| Brand | Bomag |
| Part Type | Genuine OEM |
| Description | Jack Latch |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Pneumatic Tyred Roller | BW 24 R | 00817552, 00817854 |
| Pneumatic Tyred Roller | C 560 B | 00817598 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
