The Bomag 05747297 is a genuine OEM Locking Screw designed for a wide range of Bomag tampers, vibratory plates, and reversible vibratory plates, including BT 60, BT 65, and BVT 65 tampers, BP-series vibratory plates such as the BP 20/48, BP 25/48, and BP 23/48, reversible vibratory plates including the BPR 25/40, BPR 30/38, and BPR 25/45-3, and the BW 55 E walk-behind roller. Sourced directly from Bomag, this locking screw carries the same part number 05747297 used in the original build, so you can order with confidence that it will match what came off the machine. This component is an exact OEM replacement, ensuring the correct thread form, head dimensions, and locking characteristics are maintained across every application it serves.
Key Features
- Genuine OEM Thread and Dimensional Accuracy — manufactured to Bomag's original specifications, delivering the correct thread pitch, shank diameter, and head geometry this application demands
- Broad Cross-Family Coverage — fits BT-series tampers (BT 50, BT 60, BT 60/4, BT 65, BT 65/4, BT 60 G, BT 65 G, BVT 65), BP and BVP forward vibratory plates, BPR reversible vibratory plates, and the BW 55 E walk-behind roller
- Drop-In Replacement — matches the original fastener profile so this locking screw seats and torques correctly without modification to surrounding hardware
- Positive Retention Under Vibration — the locking feature is engineered to resist backing-out in the high-vibration environments generated by compaction equipment, maintaining clamp load through continuous operation
A locking screw is a fastener engineered to resist loosening under the sustained vibration and dynamic loading that compaction equipment generates during normal use. Unlike a standard screw, it incorporates a locking feature — such as a prevailing-torque thread form, a nylon patch, or a serrated bearing surface — that maintains clamping force even as the machine cycles repeatedly through impact and vibration. When a locking screw works loose or is replaced with a standard fastener that lacks the correct locking characteristic, surrounding components can shift, wear unevenly, or suffer accelerated fatigue, leading to more extensive repairs. Using the correct OEM replacement ensures the joint retains its designed clamping load throughout the service interval.
Part Details
| Part Number | 05747297 |
|---|---|
| Brand | Bomag |
| Part Type | Genuine OEM |
| Description | Locking Screw |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Tamper | BT 60 | 00800853, 00818673, 00824399, 00824635, 00825059, 00825397, 00825399, 00825573, 00825575, 00826683, 00826853, 00826877, 00826879, 00825035 |
| Vibratory Plate | BP 10/36-2 | 00811803, 00812064, 00817411, 00817609, 00818605 |
| Vibratory Plate | BP 20/48 | 00813319, 00817421, 00819911 |
| Vibratory Plate | BP 15/36-2 | 00817412, 00811804, 00814617 |
| Vibratory Plate | BP 18/45-2 | 00817420, 00817905, 00818449, 00818603, 00811429 |
| Vibratory Plate | BP 23/48 | 00817423, 00819919, 00811650 |
| Vibratory Plate | BP 25/48 | 00817426 |
| Vibratory Plate | BP 8/34 | 00817429, 00818307 |
| Reversible Vibratory Plate | BPR 25/40 | 00817432, 00855719, 00811633 |
| Reversible Vibratory Plate | BPR 30/38-3 BPR 35/38-3 | 00817434 |
| Tamper | BT 65/4 | 00817453, 00818017, 00818199, 00818601, 00818739, 00818785, 00818833, 00824171, 00824343 |
| Tamper | BT 60/4 | 00817456, 00817997, 00818197, 00818629, 00818737, 00818783, 00818827, 00824169 |
| Walk-Behind / Light Roller | BW 55 E | 00817553, 00811021, 00811012 |
| Reversible Vibratory Plate | BPR 25/45-3 | 00817646 |
| Vibratory Plate | BP 12/50 A | 00818387 |
| Tamper | BT 65 | 00818675, 00824403, 00824637, 00824885, 00825061, 00825213, 00825401, 00825403, 00825579, 00825581, 00826537, 00826833, 00826881, 00826883, 00827317 |
| Tamper | BVT 65 | 00818677, 00824401, 00825153, 00825405, 00825577 |
| Tamper | BT 60 G | 00824891, 00825407, 00825113 |
| Tamper | BT 65 G | 00824893, 00825115, 00825409 |
| Vibratory Plate | BVP 10/30 | 00825109, 00825329, 00825467, 00826197 |
| Tamper | BT 50 | 00826373, 00826875 |
| Vibratory Plate | BP 10/30 | 00827091 |
| Reversible Vibratory Plate | BPR 25/32 | 00813338 |
| Reversible Vibratory Plate | BPR 30/38-2 | 00810115 |
| Reversible Vibratory Plate | BPR 30/38-3 | 00811419 |
| Reversible Vibratory Plate | BPR 30/38 | 00813346, 00813344 |
| Vibratory Plate | BP 10/36 | 00811814, 00811542, 00811815, 00811816 |
| Vibratory Plate | BP 15/45-2 | 00811547, 00811549, 00816306 |
| Vibratory Plate | BP 15/45 | 00811543, 00811544, 00811545, 00811546 |
| Vibratory Plate | BP 20/60 | 00811649 |
| Vibratory Plate | BP 23/60 | 00811651 |
| Vibratory Plate | BP 6/30 | 00817935 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
