The Bomag 05716294 Output Socket is a genuine OEM component designed for a wide range of Bomag pavers, tandem rollers, single drum rollers, pneumatic tyred rollers, refuse and landfill compactors, and soil compactors. This output socket is sourced directly from Bomag and built to the same specification as the part it replaces, ensuring an exact match for the machines it serves. Compatible models include BF 600 and BF 800 series pavers, BW 161, BW 190, BW 202, BW 203, BW 205, and BW 211 through BW 213 tandem and single drum rollers, the BW 28 RH pneumatic tyred roller, BC 462 and BC 472 series compactors, and the BW 332 single drum roller. Ordering by part number 05716294 confirms you are receiving the correct Bomag-authorized socket for your machine.
Key Features
- Genuine OEM Electrical Integrity — manufactured to Bomag's original output specifications, ensuring correct signal and power transmission at the socket connection point without improvised adaptation
- Direct Plug-In Replacement — this output socket seats and locks into the factory connector position on supported machines, restoring the original wiring interface without reworking harness routing
- Broad Cross-Family Coverage — fits Bomag BF 600 and BF 800 series pavers, BW-series tandem and single drum rollers including BW 211 D-5, BW 213 D-5, and BW 202 AD-4, the BW 28 RH pneumatic tyred roller, and BC 462 and BC 472 series compactors
- Prevents Electrical Faults — a worn or damaged output socket can cause intermittent signal loss, erratic machine behavior, or failed sensor readings; replacing it with part number 05716294 restores stable output continuity
- Correct Connector Seating for Safe Operation — on machines where this socket carries control or sensor output, a secure, properly rated connection is essential to safe and predictable machine response
An output socket is an electrical connector that carries a signal or power output from a control module, sensor, or harness to another component in the machine's electrical system. It provides the physical and electrical interface that allows data or current to pass reliably between parts of the circuit. When an output socket becomes worn, cracked, or corroded, the connection can become intermittent or fail entirely — leading to erratic machine behavior, fault codes, or loss of a controlled function. Replacing a failed socket with the correct OEM part restores the circuit to its intended condition and eliminates the risk of secondary electrical damage caused by a poor connection.
Part Details
| Part Number | 05716294 |
|---|---|
| Brand | Bomag |
| Part Type | Genuine OEM |
| Description | Output Socket |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Paver | BF 600 P HCE | 00800631, 00800721 |
| Paver | BF 600 C HCE | 00800633 |
| Paver | BF 600 C HCG | 00800635 |
| Paver | BF 600 C HSG | 00800637 |
| Paver | BF 600 C HSE | 00800639 |
| Paver | BF 600 P HCG | 00800641 |
| Paver | BF 600 P HSE | 00800645 |
| Paver | BF 600 C-E | 00800651 |
| Paver | BF 600 P-E | 00800653 |
| Paver | BF 600 C-G | 00800655 |
| Paver | BF 691 C | 00800661 |
| Paver | BF 800 C S500 | 00800677, 00800679, 00800827, 00800871 |
| Paver | BF 800 C S600 | 00800681, 00800683, 00800779, 00800829, 00800851, 00800873, 00824541 |
| Paver | BF 800 P S500 | 00800685, 00800687, 00800831, 00800879 |
| Paver | BF 691 C-HSE | 00800689 |
| Paver | BF 691 P-HSE | 00800691 |
| Paver | BF 691 C-HB | 00800703 |
| Paver | BF 691P-HSE | 00800705 |
| Paver | BF 600P HSE | 00800719, 00800727, 00824239 |
| Paver | BF 600C HCE | 00800725, 00800733 |
| Paver | BF 600P HCE | 00800729 |
| Paver | BF 600C HSE | 00800731 |
| Paver | BF 800 C S600 SOIL | 00800745 |
| Paver | BF 700 C-2 S 500 | 00800899, 00824493 |
| Paver | BF 600 C-2 S 500 | 00800907, 00824485, 00824489 |
| Paver | BF 600 P-2 S 500 | 00800911 |
| Paver | BF 600 P-2 S 600 | 00800949, 00825915 |
| Tandem Roller | BW 161 AD-4 | 00817641 |
| Tandem Roller | BW 202 AD-4 | 00817642, 00818381, 00818961, 00824005 |
| Tandem Roller | BW 161 ADH-4 | 00817739 |
| Tandem Roller | BW 190 AD-4 | 00817823, 00818379, 00818965, 00824009 |
| Tandem Roller | BW 190 AD-4 AM | 00817825, 00818309, 00824021 |
| Tandem Roller | BW 203 AD-4 AM | 00817837, 00818591, 00824019, 00825067 |
| Tandem Roller | BW 161 AC-4 | 00817947 |
| Single Drum Roller | BW 211 D-40 | 00818129 |
| Single Drum Roller | BW 213 D-4 | 00818293 |
| Single Drum Roller | BW 211 PD-40 | 00818319 |
| Tandem Roller | BW 161 ADH-4 CHINA | 00818365 |
| Single Drum Roller | BW211D 40 | 00818415 |
| Single Drum Roller | BW211PD 40 | 00818417 |
| Refuse / Landfill Compactor | BC 472 RB | 00818439, 00818899 |
| Refuse / Landfill Compactor | BC 472 RS | 00818441, 00818907 |
| Soil Compactor | BC 462 EB | 00818443, 00818903 |
| Refuse / Landfill Compactor | BC 462 RB | 00818445, 00818905 |
| Tandem Roller | BW 203 AD-4 | 00818599, 00818963 |
| Single Drum Roller | BW 332 | 00818725 |
| Single Drum Roller | BW 211 PD-4 | 00824391 |
| Tandem Roller | BW 202 AD-4 EU-Flex | 00824395 |
| Tandem Roller | BW 203 AD-4 AM EU-Flex | 00824397 |
| Paver | BF 600 C-2 S 600 | 00824487 |
| Paver | BF 700 C-2 S 600 | 00824491 |
| Tandem Roller | BW203AD-4 | 00824739, 00826243 |
| Tandem Roller | BW 205 AD 4 | 00824889 |
| Tandem Roller | BW 203 ADO-4 | 00825049 |
| Single Drum Roller | BW 211 D-5 | 00825241 |
| Single Drum Roller | BW 211 PD-5 | 00825269 |
| Single Drum Roller | BW 213 D-5 | 00825271 |
| Single Drum Roller | BW 213 PDH-5 | 00825275 |
| Pneumatic Tyred Roller | BW 28 RH | 00826177 |
| Single Drum Roller | BW 214 D-5 | 00826359 |
| Single Drum Roller | BW 211 D-5 SL | 00826379, 00826703 |
| Single Drum Roller | BW 213 D-5 SL | 00826383 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
