The Bomag 05766958 Relay is a genuine OEM electrical relay designed for a wide range of Bomag compaction equipment, including reversible vibratory plates, tandem rollers, walk-behind rollers, and the BMP 8500 trench compactor. As a direct OEM replacement, this relay matches the original switching specifications required by Bomag's electrical systems, ensuring correct operation from the moment it is installed. This component fits models including the BPR 35/42 D, BPR 35/60 D, BPR 40/60 D, BPR 45/55 D, BPR 50/55 D, BPR 55/65 D, BPR 60/65 D, BPR 65/70 D, BPR 70/70 D, BPR 100/80 D, BPH 80/65 S, BW 6, BW 6 S, BW 71 EHB-2, BW 135 AD, BW 138 AD, BW 138 AC, BW 138-AD, and BMP 8500. Sourcing part number 05766958 directly through DHS Equipment guarantees you are receiving an authentic Bomag component backed by OEM quality standards.
Key Features
- OEM Switching Precision — manufactured to the exact coil voltage, contact rating, and switching load specifications of the original relay, ensuring correct circuit behavior across Bomag's electrical architecture
- Drop-In Electrical Replacement — matches the original connector configuration and mounting footprint, so this relay installs directly into the existing relay socket without modification
- Broad Bomag Fitment — compatible with the BPR and BPH reversible vibratory plate lines, BW 135 AD and BW 138 AD tandem rollers, BW 6 and BW 71 EHB-2 walk-behind rollers, and the BMP 8500 trench compactor
- Protects Downstream Electrical Components — a correctly functioning relay isolates high-current circuits from low-current control signals, preventing voltage spikes and premature failure of switches, controllers, and actuators
- Electrical System Safety — a failed or incorrectly rated relay can cause unintended circuit energization or control failure; using the correct OEM-spec relay maintains safe, predictable machine response
A relay is an electrically operated switch that allows a low-current control signal — from an operator switch or control module — to safely open or close a high-current circuit powering components such as the starter, fuel solenoid, or vibration system. In Bomag compaction equipment, the relay acts as a critical link between the operator's inputs and the machine's working systems, routing power reliably without exposing the control electronics to damaging load currents. When a relay fails, the circuit it controls may stop functioning entirely or behave intermittently, causing starting failures, loss of vibration, or unpredictable electrical behavior that can be difficult to diagnose without first replacing the relay.
Part Details
| Part Number | 05766958 |
|---|---|
| Brand | Bomag |
| Part Type | Genuine OEM |
| Description | Relay |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Reversible Vibratory Plate | BPR 100/80 D | 00817965, 00824253, 00824331, 00824379, 00825143, 00825553, 00825793, 00825795, 00826743, 00826745, 00825549 |
| Reversible Vibratory Plate | BPR 45/55 D | 00817981, 00818493, 00818765, 00824247, 00824321, 00824375, 00825007, 00825015, 00825535, 00825803, 00826679 |
| Reversible Vibratory Plate | BPR 55/65 D | 00817989, 00818497, 00818767, 00824249, 00824325, 00825009, 00825537, 00825787, 00826681 |
| Reversible Vibratory Plate | BPR 65/70 D | 00817993, 00818567 |
| Reversible Vibratory Plate | BPH 80/65 S | 00818011, 00824255, 00824299, 00824367, 00825511, 00826089, 00826675, 00825779 |
| Walk-Behind / Light Roller | BW 71 EHB-2 | 00818083 |
| Reversible Vibratory Plate | BPR 35/42 D | 00818087, 00818485, 00818759, 00824313, 00824771, 00825531, 00825807, 00826515, 00827469 |
| Reversible Vibratory Plate | BPR 35/60 D | 00818091, 00818489, 00818763, 00824319, 00824373, 00824773, 00824793, 00825533, 00825785, 00826519, 00827471 |
| Tandem Roller | BW 135 AD | 00818357 |
| Tandem Roller | BW 138 AD | 00818359 |
| Tandem Roller | BW 138 AC | 00818361 |
| Tandem Roller | BW 138-AD | 00818389 |
| Walk-Behind / Light Roller | BW 6 | 00818665 |
| Trench Compactor | BMP 8500 | 00818667 |
| Walk-Behind / Light Roller | BW 6 S | 00818683 |
| Reversible Vibratory Plate | BPR 70/70 D | 00818747, 00824251, 00824329, 00824377, 00825117, 00825141, 00825547, 00825551, 00825557, 00825797, 00825799, 00826739, 00826741 |
| Reversible Vibratory Plate | BPR 50/55 D | 00824323, 00824381, 00824775, 00824779, 00825011, 00825017, 00825245, 00825539, 00825801, 00826477, 00826845 |
| Reversible Vibratory Plate | BPR 60/65 D | 00824327, 00824383, 00824777, 00824781, 00825013, 00825019, 00825247, 00825541, 00825789, 00826475, 00826847 |
| Reversible Vibratory Plate | BPR 40/60 D | 00824897, 00825811, 00826523, 00827473 |
| Reversible Vibratory Plate | BPR 40/60 D/E | 00825545 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
Why Buy From DHS Equipment
Every part is verified against the manufacturer's part number before it ships, so what you order is what arrives. We carry parts from leading OEM brands and our own DHS Quality Parts line of professional aftermarket components. Need help finding the right part? Our team is available to confirm compatibility whenever you need it. Orders are processed fast to keep your jobs on track. We don't just sell parts. We keep you jobsite ready.
Questions? Contact our team at [email protected] or 866-611-9369 — DHS Equipment is here to help you maintain peak performance.
