Bomag 05568736 Toggle Link Button

The Bomag 05568736 Toggle Link Button is a genuine OEM component designed for a wide range of Bomag BW-series tandem rollers and single drum rollers. Sourced directly from Bomag, this replacement button matches the exact form and function of the original factory-installed part, ensuring correct operation of the toggle link control interface on your machine. This toggle link button is confirmed to fit an extensive lineup of BW tandem rollers — including the BW 80 AD-2, BW 90 AD-2, BW 100 AC-3, BW 100 AD-3, BW 100 AC-4, BW 100 AD-4, BW 115 AC-3, BW 115 AD-3, BW 120 AC-3, BW 120 AD-3, BW 120 AC-4, BW 120 AD-4, BW 125 ACH, BW 125 ADH, BW 125 AC-4, BW 125 AD-4, BW 131 AD-2, BW 131 ACW-2, BW 131 AD-3, BW 131 ACW-3, BW 131 AD-5, BW 131 ACW-5, BW 135 AC, BW 135 AD, BW 138 AC, BW 138 AD, BW 141 AD-2, BW 144 AD-2, BW 151 AC-2, BW 151 AD-2, BW 154 AD-2, BW 80 ADS, and BW 90 AC-2 — as well as single drum rollers including the BW 124 DH-3, BW 124 PDH-3, BW 124 DH-4, BW 124 PDH, BW 124 DH-40, BW 124 PDH-40, BW 145 D-3, BW 145 DH-3, BW 145 PDH-3, BW 145 D-3, BW 177 D-3, BW 177 DH-3, BW 177 PDH-3, BW 211 D-3, BW 212 D-3, BW 212 D-30, BW 213 D-3, BW 213 DH-3, BW 213 PDH-3, BW 214 DH-3, BW 216 D-3, BW 216 DH-3, BW 216 DHC-3, BW 219 DH-3, BW 219 PDH-3, BW 225 D-3, BW 225, BW 178 D-3, and C 815 C, C 825 C, and C 850 C single drum rollers. When the correct OEM part number matters, Bomag part number 05568736 gives you a verified, direct-fit solution straight from the source.

Key Features

• Genuine OEM Switch Integrity — manufactured to Bomag's original electrical and mechanical specifications, ensuring the toggle link button delivers the correct actuation feel and contact function every time it is pressed
• Direct-Fit Replacement — mounts into the existing control panel position with no alterations to wiring or hardware, making swap-out straightforward for experienced operators and technicians
• Broad BW-Series Coverage — fits an extensive range of Bomag BW tandem rollers and single drum rollers across multiple generation designations, including -2, -3, -4, -5, and -40 variants, as well as C-series single drum rollers
• Control System Reliability — a worn or failed toggle link button can interrupt operator commands to critical machine functions; replacing it with the correct OEM component restores full, predictable control response
• Operator Safety Assurance — as a control interface component, an OEM-spec toggle link button ensures switching inputs are transmitted accurately, supporting safe, responsive machine operation on the jobsite

The toggle link button is a control panel switch that allows the operator to activate or toggle specific machine functions through the roller's electrical system. When the button is pressed, it completes or interrupts an electrical circuit that signals the machine's control system to engage or disengage the linked function. Over time, repeated use can cause contact wear, sticky actuation, or complete switch failure — any of which can leave the operator without reliable control of that function. Replacing a faulty toggle link button promptly with a genuine OEM part restores accurate, responsive operation and prevents secondary issues caused by erratic or absent control signals.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
