The Genie 13120GT is a genuine OEM Elbow, 070220-6-6 built for Genie S and Z series boom lifts. As a direct OEM replacement, this elbow is manufactured to the same specifications as the original, ensuring a correct, consistent connection at the fitting point it serves. This part is confirmed to fit a broad range of telescopic and articulating boom lift models, including the S-40, S-45, S-60, S-65, S-80, S-85, Z-30/20, Z-30/20 N, Z-30/20HD, Z-34/22 N, Z-34/22 DC, Z-45/22, Z-45/22 MP, and Z-60/34. Cross-reference part number 13120GT against your machine's parts manual to confirm it is the correct item for your unit before ordering.
Key Features
- Genuine OEM Construction — Manufactured to Genie's original specifications for dimensional accuracy and material integrity at the fitting interface.
- Direct-Fit Replacement — Designed to install in place of the original elbow with no rework to the surrounding connections or hardware.
- Broad Boom Lift Compatibility — Fits a wide range of Genie S series telescopic booms and Z series articulating booms, covering multiple configurations within each family.
- Sound Fitting, Sound Flow — A correctly seated elbow maintains a leak-free connection at the directional change point it serves; a cracked or weeping fitting should be replaced promptly to prevent fluid loss and keep the circuit operating correctly.
- Genuine Part Assurance — Sourced directly through authorized Genie supply channels, so you can be confident this part matches the original specification for your machine.
An elbow fitting routes a fluid line through a directional change — typically 45° or 90° — where a straight connection is not practical given the layout of the machine. On Genie boom lifts, fittings like this one are found wherever plumbing must change direction to clear structural members or other components. A loose, cracked, or cross-threaded elbow allows fluid to escape at the junction, leading to pressure loss in the circuit it serves and potential contamination of the surrounding area. Replacing a damaged elbow with the correct OEM part restores a secure, leak-free connection and keeps the circuit performing as intended.
Part Details
| Part Number | 13120GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Elbow, 070220-6-6 |
Compatibility & Fitment
| Name | Model |
|---|---|
| S-60 | S-60 |
| S-40 | S-40 |
| S-45 | S-45 |
| S-80 | S-80 |
| S-85 | S-85 |
| S-65 | S-65 |
| Z-60/34 | Z-60/34 |
| Z-30/20 N | Z-30/20 N |
| Z-34/22 N | Z-34/22 N |
| Z-34/22 DC | Z-34/22 DC |
| Z-30/20HD | Z-30/20HD |
| Z-30/20 | Z-30/20 |
| Z-45/22 MP | Z-45/22 MP |
| Z-45/22 | Z-45/22 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
