The Wacker Neuson Guide Cylinder is a genuine OEM component designed for the BS50, BS62, BS65, AS50e, AS60e, AS62e, and AS68e series rammers and jumping jacks. As a factory-authorized part, it is manufactured to the exact tolerances required for correct rammer operation, ensuring consistent, repeatable performance across every compaction cycle. This part covers an extensive range of Wacker Neuson rammer models, making it the right choice whether you are servicing a BS50-2, BS50-4As, BS62-2, BS62-4A, or any of the compatible AS-series machines. Sourcing the genuine OEM eliminates guesswork and keeps your machine running to the specification it was built for.
Key Features
- OEM Dimensional Accuracy — Manufactured to Wacker Neuson's exact bore and stroke tolerances, ensuring the cylinder guides the rammer piston without play or misalignment during compaction.
- Direct Drop-In Replacement — Matches original mounting points and dimensions for the BS50, BS62, BS65, AS50e, AS60e, AS62e, and AS68e series, so installation follows the standard service procedure without modification.
- Broad Model Coverage — A single part number covers BS50-2, BS50-4As, BS62-2, BS62-4A, BS65-4As, AS50e, AS60e, AS62e/25, AS68e/25, AS62ve/25, and AS68ve/25 variants, including Sunbelt-spec machines.
- Sustained Compaction Force — A correctly fitted guide cylinder keeps the piston stroke true and consistent, preserving rated impact force and preventing the erratic compaction that a worn or cracked cylinder causes.
- Genuine Wacker Neuson Part — Supplied as an authentic OEM component under part number 5100038429, backed by Wacker Neuson's parts program for quality assurance.
The guide cylinder is a core structural component in a rammer's drive assembly. It houses and directs the reciprocating piston, maintaining the precise linear motion needed to generate consistent downward impact force into the ground. When the guide cylinder is worn, cracked, or out of tolerance, the piston loses alignment, causing uneven compaction, increased vibration, accelerated wear on surrounding components, and ultimately machine failure. Replacing a damaged guide cylinder with a genuine OEM part restores the correct stroke geometry and protects the integrity of the entire rammer mechanism.
Part Details
| Part Number | 5100038429 |
|---|---|
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Guide Cylinder |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| BS50-4AS 11IN US | BS50-4As 11in US | 5100030598 |
| BS50-4As 11in | BS50-4As 11in | 5100030599 |
| BS50-2plus 11in US | BS50-2plus 11in US | 5100030594 |
| BS50-2PLUS 11IN HA US | BS50-2plus 11in ha US | 5100030595 |
| BS50-2plus 11in | BS50-2plus 11in | 5100030596 |
| BS50-2plus 6in (24mm) | BS50-2plus 6in (24mm) | 5100030597 |
| AS50e | AS50e | 5100026850, 5100053792 |
| BS50-2 11IN US | BS50-2 11in US | 5100030590 |
| BS50-2 11in | BS50-2 11in | 5100030591 |
| BS50-2 6in | BS50-2 6in | 5100030592 |
| AS62e/25 | AS62e/25 | 5100061968 |
| AS68e/25 | AS68e/25 | 5100061972 |
| AS60e | AS60e | 5100049787, 5100052267 |
| BS50-2 10IN | BS50-2 10in | 5100058346 |
| BS65-4As 11in | BS65-4As 11in | 5100061307 |
| BS62-2b/28 | BS62-2b/28 | 5100061964 |
| BS62-2lb/16 | BS62-2lb/16 | 5100061965 |
| BS62-4Ab/28 | BS62-4Ab/28 | 5100061966, 5100070526 |
| BS50-2 11'' | BS50-2 11in o. bsz | 5100068309 |
| 4 stroke rammer BS50-4As, 280 mm adapter | BS50-4As 11in o. bsz | 5100068310 |
| BS62-4A/28 | BS62-4A/28 | 5100068373 |
| BS62-2/28 | BS62-2/28 | 5100070149 |
| BS62-2/25 | BS62-2/25 | 5100070151 |
| Rammer BS62-2lb/16 Sunbelt | BS62-2lb/16 Sunbelt | 5100070528 |
| AS62e/25 Sunbelt | AS62ve/25 Sunbelt | 5100075650 |
| AS62e/25 Sunbelt | AS68ve/25 Sunbelt | 5100075651 |
| AS62ve/25 | AS62ve/25 | 5100081385 |
| AS68ve/25 | AS68ve/25 | 5100081386 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
