The Genie 217313GT Z-135 Bell Crank Angle Sensor Kit is a genuine OEM assembly built for the Genie Z-135/70 articulating boom lift. Sourced directly from Genie, this kit delivers the exact components needed to restore proper angle sensing at the bell crank on the Z-135/70. Cross-reference part number 217313GT against your machine's parts manual to confirm it is the correct kit for your unit before ordering.
Key Features
- Genuine OEM Components — Manufactured to Genie's exact specifications, ensuring dimensional conformity and material grade match the original assembly.
- Direct-Fit Replacement — Engineered specifically for the Z-135/70, this kit installs in place of the original without modification.
- Correct Model Fitment — Confirmed for the Genie Z-135/70 articulating boom lift; always verify part number 217313GT in your parts manual before installation.
- Angle Sensing Integrity — A functioning bell crank angle sensor allows the machine's control system to accurately track boom position; a failed or out-of-specification sensor can cause incorrect readings and restricted machine operation.
- Operational Safety — Accurate boom angle data is essential for safe operation of an articulating boom lift at height; replacing a worn or failed sensor with the correct OEM kit helps maintain the integrity of the machine's position monitoring system.
The bell crank angle sensor monitors the rotational position of the bell crank linkage in the boom system, feeding position data to the machine's control system so it can accurately track and limit boom movement within safe operating parameters. When the sensor wears out or fails, the control system may receive inaccurate position signals, which can trigger fault codes, restrict boom functions, or prevent the machine from operating altogether. Replacing the sensor with the correct OEM kit restores accurate angle feedback and returns the boom to normal, reliable operation.
Part Details
| Part Number | 217313GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Z-135 Bell Crank Angle Sensor Kit |
Compatibility & Fitment
| Name | Models |
|---|---|
| Z-135/70 | Z-135/70 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
