The Multiquip 009120302 is a genuine OEM Socket Head Bolt 16X30 designed for MVH-series reversible plate compactors. As a direct OEM replacement, this bolt is manufactured to the exact dimensions and thread specification required by Multiquip for correct installation and sustained clamping force. Verified fitment covers the MVH508DE, MVH508DZ, MVH508GV, MVH508GH, MVH408DE, MVH408DZ, MVH408GV, MVH408GH, MVH308DE, MVH308DZ, MVH308GH, and MVH304GSB — making it a single correct-fit solution across the full MVH heavy-duty reversible plate compactor range sold through DHS Equipment.
Key Features
- OEM-Grade Fastener Integrity — Manufactured to Multiquip's exact torque and shear-load ratings for MVH-series compactor applications, ensuring consistent clamping performance under continuous vibration.
- Correct Thread and Socket Geometry — The M16x30 socket head profile installs directly with a standard hex key driver, matching the factory-specified drive recess without adapter fittings.
- Broad MVH Series Coverage — Fits MVH508, MVH408, MVH308, and MVH304 model variants across diesel and gasoline configurations, including DE, DZ, GV, GH, and GSB suffix units.
- Vibration-Resistant Retention — Socket head cap bolts in plate compactor assemblies are subject to sustained high-frequency vibration; an OEM-spec replacement maintains the torque retention characteristics the machine was engineered around.
- Genuine Multiquip Part — Supplied as an authentic OEM component, part number 009120302, sourced through authorized Multiquip distribution channels at DHS Equipment.
A socket head bolt in a plate compactor assembly serves as a structural fastener that secures major components — such as the exciter housing, base plate, or drive assembly — under the constant stress of high-frequency vibration. Because reversible plate compactors like the MVH series generate significant compaction force in both directions, these fasteners must maintain precise clamping load throughout operation. A bolt that is worn, stretched, or out of specification can lead to loosening, component misalignment, or accelerated wear on the parts it holds together.
Part Details
| Part Number | 009120302 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Socket Head Bolt 16X30 |
Compatibility & Fitment
| Name | Model |
|---|---|
| Plate Compactors | MVH508DE |
| Plate Compactors | MVH408DE |
| Plate Compactors | MVH308DZ |
| Plate Compactors | MVH308DE |
| Plate Compactors | MVH508GV |
| Plate Compactors | MVH408GV |
| Plate Compactors | MVH308GH |
| Plate Compactors | MVH508GH |
| Plate Compactors | MVH508DZ |
| Plate Compactors | MVH408GH |
| Plate Compactors | MVH408DZ |
| Plate Compactors | MVH304GSB |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
