The Multiquip 01551802 Instrument Box 12V is a genuine OEM component designed for the MVH502DSB and MVH502DSB2 reversible plate compactors. As an authentic Multiquip part, it is manufactured to the same specification as the original, ensuring a direct, correct-fit installation without guesswork. This instrument box is a critical electrical housing component that keeps your operator controls and gauges protected and functioning correctly on the jobsite. Sourced directly through authorized Multiquip supply channels, the part is the right part for keeping your MVH502DSB series compactor running as intended.
Key Features
- Genuine OEM Electrical Integrity — Manufactured to exact 12V system specifications, ensuring correct voltage compatibility and secure housing for all connected instrumentation on the MVH502DSB series.
- Direct-Fit Installation — Engineered to mount in the original bracket position with existing hardware, making swap-out straightforward for technicians familiar with the MVH502DSB platform.
- Confirmed Compactor Fitment — Verified for use on MVH502DSB and MVH502DSB2 reversible plate compactors, so you can order with confidence for the correct machine.
- Protects Critical Operator Controls — Houses and shields the electrical instrumentation that operators rely on to monitor and control compactor performance; a damaged or failed box exposes wiring to vibration, moisture, and debris.
- Electrical Safety Compliance — A properly sealed and intact instrument box maintains correct isolation of the 12V electrical circuit, reducing the risk of shorts or unintended contact with live terminals during operation.
The instrument box serves as the protective enclosure for the 12V electrical instrumentation and control components on the plate compactor. It shields gauges, switches, and wiring connections from the constant vibration, dust, and moisture exposure that heavy compaction work generates. When the instrument box is cracked, broken, or missing, internal components become vulnerable to damage that can cause erratic readings, electrical faults, or complete loss of operator controls — making prompt replacement essential to safe and accurate machine operation.
Part Details
| Part Number | 01551802 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Instrument Box 12V |
Compatibility & Fitment
| Name | Model |
|---|---|
| Plate Compactors | MVH502DSB |
| Plate Compactors | MVH502DSB2 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
