The Multiquip 04102600 Shim 1.20/42.2 1D81Z is a genuine OEM shim designed for the MVH508DZ reversible plate compactor. Sourced directly from Multiquip, this shim delivers the precise dimensional tolerancing required to maintain correct mechanical clearances within the compactor's drivetrain or exciter assembly. Fitment is confirmed for the MVH508DZ, and the part number 04102600 should be verified against your machine's parts manual before ordering.
Key Features
- Genuine OEM Dimensional Accuracy — Manufactured to exact 1.20 mm thickness and 42.2 mm diameter specifications, ensuring correct mechanical clearance without guesswork or on-site modification.
- Direct Drop-In Replacement — Designed to seat and stack exactly as the original shim, maintaining proper component alignment and preload in the assembly.
- Confirmed MVH508DZ Fitment — Verified for use on the Multiquip MVH508DZ reversible plate compactor; always cross-reference part number 04102600 with your machine's parts manual.
- Preserves Exciter Assembly Integrity — A correctly sized shim keeps rotating and reciprocating components operating within their intended clearance range, preventing premature wear on adjacent parts.
- OEM Quality Assurance — As a genuine Multiquip part, 04102600 meets the same material and tolerance standards as the original component installed at the factory.
A shim is a thin, precision-machined spacer used to set or adjust the clearance between mechanical components — such as bearings, shafts, or housings — within an assembly. In a reversible plate compactor like the MVH508DZ, shims play a critical role in maintaining the correct fit and preload within the exciter or drive assembly, preventing unwanted movement and excessive wear. When a shim is worn, deformed, or missing, adjacent components can shift out of alignment, leading to accelerated bearing wear, vibration irregularities, and potential damage to the surrounding assembly.
For equipment support or fitment questions, contact the DHS Equipment team directly.
Part Details
| Part Number | 04102600 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Shim 1.20/42.2 1D81Z |
Compatibility & Fitment
| Name | Model |
|---|---|
| Plate Compactors | MVH508DZ |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
