The Multiquip 0601806422 is a genuine OEM Circuit Breaker CB2 30A designed for DLW-300ES and DLW-300ESA series diesel light welder/generator units. As a direct Multiquip OEM component, this breaker is built to the exact electrical specifications of the original, ensuring correct trip threshold and reliable circuit protection for your machine. Confirmed fitment includes the DLW-300ES, DLW-300ESA, and associated DC welder/AC generator variants. When your existing breaker trips and will not reset, or fails to protect downstream circuits, this is the part you need to restore full operation.
Key Features
- 30A Rated Circuit Protection — Matched to the CB2 position's exact amperage rating, ensuring the breaker trips at the correct threshold rather than under- or over-protecting the circuit.
- Genuine OEM Component — Sourced directly from Multiquip, this breaker carries the same electrical characteristics as the unit installed at the factory, with no substitution of internal contact materials or trip mechanisms.
- Direct Drop-In Replacement — Engineered to the same mounting footprint and terminal configuration as the original CB2 position, allowing straightforward installation without modification to the breaker panel.
- Confirmed Fitment for DLW-300ES and DLW-300ESA — Verified for the DLW-300ES, DLW-300ESA, and related DC welder/AC generator variants in the DLW-300 family.
A circuit breaker in a diesel light welder like the DLW-300ES acts as the primary overcurrent protection device for a specific circuit within the machine's electrical panel. When current draw exceeds the rated 30 amps — due to a fault, overload, or short — the breaker trips and interrupts the circuit before damage can occur to wiring, components, or connected tools. A breaker that trips repeatedly and will not hold, or one that fails to trip when it should, compromises both the machine's output and the safety of anyone working around it. Replacing a failed CB2 breaker with the correct Multiquip 0601806422 restores proper circuit protection and gets the unit back to productive operation.
Part Details
| Part Number | 0601806422 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Circuit Breaker CB2 30A |
Compatibility & Fitment
| Name | Models |
|---|---|
| Welders | DLW-300ES, DLW-300ESA, DLW300ES ESA ESA1 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
