The Multiquip 06513-024 is a genuine OEM Cap Screw 1/2-20 x 3 Grade 5 designed for the MS18E, MS18H5.5, and MS18H8 masonry saws. As a Genuine OEM part, it matches the original hardware specification exactly, ensuring a proper fit into existing threaded fastener positions without guesswork. This cap screw is sourced directly through the Multiquip parts program and sold by DHS Equipment as an authorized distributor. If you're servicing or reassembling a Multiquip masonry saw, part 06513-024 is the correct replacement to restore the machine to its original condition.
Key Features
- Grade 5 Strength Rating — Medium-carbon steel construction meeting Grade 5 tensile requirements, providing the clamping force and shear resistance expected in saw assembly fastener applications.
- Exact Thread and Length Match — 1/2-20 UNF thread pitch and 3-inch length match the original fastener specification, threading directly into existing tapped holes without rework.
- Confirmed Masonry Saw Fitment — Verified for MS18E, MS18H5.5, and MS18H8 masonry saw models, so you can order with confidence for the correct machine.
- Genuine OEM Hardware — Supplied as a Multiquip OEM part, carrying the same material grade and dimensional tolerances as the fastener originally installed at the factory.
- Supports Structural Integrity of the Assembly — Using the correct grade and size fastener maintains proper torque retention across the assembly — under-spec hardware can loosen under vibration and compromise component alignment.
A cap screw is a fully threaded or partially threaded fastener used to clamp two or more components together, typically threading into a tapped hole rather than using a nut. In masonry saw applications, cap screws secure structural and mechanical assemblies — such as blade guards, motor mounts, and frames — that must remain firmly fixed under the continuous vibration and load of cutting operations. Using the correct grade is critical: a fastener with insufficient tensile strength can stretch, strip, or fail under load, leading to component loosening, misalignment, or unsafe operating conditions. Replacing a worn or damaged fastener with the OEM-specified 06513-024 restores the clamped joint to its intended holding force.
Part Details
| Part Number | 06513-024 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Cap Screw 1/2-20 x 3 Grade 5 |
Compatibility & Fitment
| Name | Model |
|---|---|
| Masonry Saws | MS18E |
| Masonry Saws | MS18H5.5 |
| Masonry Saws | MS18H8 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
