Multiquip 23561 Bracket Exhaust Mount W/A HHXD5

The Multiquip 23561 is a genuine OEM Bracket Exhaust Mount W/A HHXD5 designed for the HHXD5 and HHXD5-ES Whiteman ride-on power trowels. Sourced directly from Multiquip, this bracket is the correct factory replacement for maintaining a secure and properly aligned exhaust system on your machine. Confirm part number 23561 against your equipment's parts manual before ordering to ensure an exact match for your serial number range.

Key Features

• Genuine OEM Construction — Manufactured to Multiquip's original design tolerances, ensuring the bracket holds the exhaust assembly at the correct mounting angle and load rating for sustained operation.
• Direct-Mount Replacement — Engineered to align with the existing mounting points on the HHXD5 and HHXD5-ES trowel frames, so installation follows the original service procedure without modification to surrounding hardware.
• Confirmed HHXD5 and HHXD5-ES Fitment — Validated for use on Whiteman HHXD5 and HHXD5-ES ride-on mechanical trowels; verify against your parts manual for serial number applicability.
• Exhaust System Stability — A structurally sound exhaust mount bracket keeps the exhaust assembly from shifting under vibration, preventing stress fractures, exhaust leaks, and damage to adjacent components.
• Exhaust Heat and Vibration Management — Correct bracket fitment ensures the exhaust is properly isolated from the frame, helping protect nearby components from heat exposure and repetitive vibration fatigue.

The exhaust mount bracket secures the exhaust assembly to the trowel's frame, holding the muffler and exhaust pipe in the correct position during operation. Without a properly functioning bracket, the exhaust system is exposed to the constant vibration produced by a ride-on trowel, which can cause the assembly to shift, crack mounting points, or contact heat-sensitive components. Replacing a worn or broken bracket promptly keeps the exhaust system properly supported and prevents secondary damage to the machine.

DHS Equipment is an authorized Multiquip parts distributor. For fitment questions or help confirming part number 23561 is correct for your HHXD5 or HHXD5-ES trowel, contact our parts team directly.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
