The Multiquip 23620-001 Carriage Bolt 1/4-20 x 1 is a genuine OEM fastener designed for JWN24HTCSL and JWN24HSCSL power trowels. As a direct Multiquip OEM component, this carriage bolt is manufactured to the exact thread pitch, diameter, and length specified for these machines, ensuring a correct, secure fit every time. Sourced directly through authorized Multiquip distribution, part number 23620-001 is the same bolt used in original assembly — no guesswork on sizing or compatibility.
Key Features
- Genuine OEM Thread Specification — Machined to 1/4-20 thread pitch and 1-inch length as specified by Multiquip, ensuring consistent torque retention and clamping force in the trowel assembly.
- Correct Head Profile for Flush Seating — The rounded carriage bolt head with square neck seats flush against the mounting surface, locking in place without requiring a wrench on the bolt head during installation.
- Verified Fitment for JWN Series Trowels — Confirmed OEM replacement for JWN24HTCSL and JWN24HSCSL walk-behind power trowels.
- Structural Fastener Integrity — A worn, stripped, or incorrect-spec fastener can lead to loose components during operation; replacing with the correct OEM bolt restores proper clamping and component alignment.
- Direct OEM Source via DHS Equipment — Authorized Multiquip parts distribution means you receive the exact part number specified in the machine's parts manual, not a substitute.
A carriage bolt is a structural fastener used to join and secure components within the trowel assembly. Its distinctive domed head and square shoulder beneath it are designed to resist rotation as a nut is tightened from the opposite side, creating a firm, vibration-resistant connection. When a carriage bolt becomes stripped, corroded, or lost, the affected joint can loosen under the continuous vibration of trowel operation, leading to misalignment or component movement that affects finish quality and safe machine operation.
For fitment questions or parts support, contact DHS Equipment — your authorized Multiquip parts source.
Part Details
| Part Number | 23620 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Carriage Bolt 1/4-20 x 1 |
Compatibility & Fitment
| Name | Model |
|---|---|
| Power Trowels | JWN24HTCSL |
| Power Trowels | JWN24HSCSL |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
