The Multiquip 3-10056 Bow RW-1504HF is a genuine OEM replacement designed for RW1504HF (up to S/N ) and P33/24 series walk-behind rollers. As a direct OEM component, this part is manufactured to the same standards as the original, ensuring proper fit and function across compatible Multiquip roller models. Sourced through DHS Equipment, you can be confident you are receiving an authentic Multiquip part backed by the manufacturer. Verify your model code and serial number before ordering to confirm compatibility with your specific machine.
Key Features
- Genuine OEM Construction: — Manufactured to original Multiquip specifications, ensuring the bow maintains its correct geometry and structural integrity as designed for these roller models.
- Serial Number Specific Fitment: — Confirmed fit for RW1504HF units up to S/N 1534188, as well as P33/24 HHMR-BD with Blade and P33/24 FR/FC/FCR configurations — always verify your serial number before ordering.
- Direct Drop-In Replacement: — Engineered to mount in the same position as the original bow, with matching attachment points so no fabrication or custom fitting is needed.
- Structural Reliability: — A properly fitted bow keeps the roller frame aligned during operation; a bent or failed bow can cause uneven compaction passes and increased wear on surrounding frame components.
- Broad P33/24 Series Coverage: — Compatible across multiple P33/24 variants including HHMR-BD with Blade, FR, FC, and FCR configurations, making it a versatile stocking part for fleets running mixed roller models.
The bow on a walk-behind roller is a structural frame component that maintains the shape and rigidity of the machine's chassis assembly. It supports the alignment of key operating components and helps absorb stress transmitted through the frame during compaction work. When a bow becomes bent, cracked, or otherwise compromised, it can affect the handling and balance of the roller, leading to uneven results on the pass and potential stress on adjacent frame and drive components.
Part Details
| Part Number | 3-10056 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Bow RW-1504HF |
Compatibility & Fitment
| Name | Model |
|---|---|
| Rollers | RW1504HF up to S/N 1534188 |
| Rollers | P33/24 HHMR-BD w/Blade |
| Rollers | P33/24 FR/FC/FCR |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
