The Multiquip 31630ZL0V31 Charge Coil Assembly is a genuine OEM component designed for the GAW135H gasoline arc welder. As an authorized Multiquip OEM part, the part delivers the correct electrical output specifications required to keep the charging system operating as engineered. Confirm your model number against the GAW135H fitment before ordering to ensure a direct, correct-fit installation.
Key Features
- OEM-Correct Winding Specification — Manufactured to the exact coil winding and output parameters required by the GAW135H charging circuit, ensuring accurate voltage generation across the operating range.
- Direct Drop-In Installation — Engineered to mount to the original stator position with matching connector and bolt pattern, allowing straightforward installation without adapters or modification.
- Confirmed GAW135H Fitment — Verified for the Multiquip GAW135H gasoline arc welder; always cross-reference your model code before ordering.
- Charging System Integrity — A functioning charge coil sustains battery voltage during operation, keeping ignition and electrical systems properly powered throughout the workday.
- Genuine Multiquip OEM Part — Sourced directly through the Multiquip OEM supply chain, ensuring you receive the correct part with full manufacturer traceability.
The charge coil assembly is a core component of the engine's stator system, generating alternating current as the flywheel rotates past its windings. This current is routed to the regulator/rectifier, where it is converted and regulated to maintain the correct battery charge voltage during engine operation. When the charge coil fails or degrades, the battery will no longer receive a proper charge, leading to hard-starting conditions, voltage drop under load, and eventual electrical system failure on the welder.
Part Details
| Part Number | 31630ZL0V31 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Charge Coil Assembly |
Compatibility & Fitment
| Name | Model |
|---|---|
| Welders | GAW135H |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
