The Multiquip 457333710 Drain Guide is a genuine OEM component designed for MVH502DSB and MVH502DSB2 reversible plate compactors. Sourced directly from Multiquip, this part matches the original specification installed at the factory, so it seats and functions exactly as intended. If you're servicing or rebuilding an MVH502DSB or MVH502DSB2, using the correct OEM drain guide ensures the drainage path remains properly channeled and sealed against leaks or misalignment.
Key Features
- Genuine OEM Construction — Manufactured to the same material grade and dimensional tolerance as the original part, ensuring proper fit within the compactor's drain system without modification.
- Direct Replacement for MVH502DSB and MVH502DSB2 — Confirmed fitment for both variants of the MVH502 reversible plate compactor series, with correct mounting geometry for a straightforward installation.
- Maintains Proper Drainage Channeling — Guides fluid to the correct drain point, preventing pooling or misdirected flow that could contaminate surrounding components or obscure fluid level readings.
- Resists Wear from Repeated Service Intervals — Built to withstand the vibration and heat exposure common in heavy-duty plate compactor operation, maintaining structural integrity over multiple service cycles.
- Verified by Part Number 457333710 — Cross-reference this number against your machine's parts manual to confirm the correct replacement before ordering.
The drain guide directs fluid — typically oil or coolant runoff — away from the machine's internal components and toward the designated drain outlet during service or operation. In a reversible plate compactor like the MVH502DSB, maintaining clean and directed drainage is important for keeping the exciter housing and surrounding mechanical parts free from fluid contamination. A missing, cracked, or improperly fitted drain guide can allow fluid to pool in unintended areas, leading to component corrosion or inaccurate fluid level assessments during routine maintenance checks.
Part Details
| Part Number | 457333710 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Drain Guide |
Compatibility & Fitment
| Name | Model |
|---|---|
| Plate Compactors | MVH502DSB |
| Plate Compactors | MVH502DSB2 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
