The Multiquip 565004 is a genuine OEM Depth Indicator Extension Spring designed for the SP Series Pavement Saws and SP4 Flat Saws. As a direct OEM replacement, this spring is manufactured to the same specifications as the original component and confirms compatibility across a wide range of Street Pro Series models including SP303516, SP303520, SP303526, SP303530, SP605716, SP605720, SP605726, SP605730, SP605736, and SP6457. Sourcing the correct OEM spring ensures the depth indicator mechanism operates as intended, giving operators accurate blade depth readings on every cut. DHS Equipment stocks this part ready to ship so you can get your saw back in service without delay.
Key Features
- Genuine OEM Spring Tension: — Manufactured to the original tension specification so the depth indicator returns and holds position correctly under field conditions.
- Direct Drop-In Replacement: — Matches the original mounting points and hook geometry of the depth indicator assembly for a straightforward swap during service.
- Broad SP Series Compatibility: — Confirmed fit across SP303516, SP303520, SP303526, SP303530, SP605716, SP605720, SP605726, SP605730, SP605736, SP6457, and SP4 models.
- Accurate Depth Control: — A correctly tensioned extension spring keeps the depth indicator responsive and consistent, which is critical when setting blade depth on pavement cutting applications.
- Cutting Accuracy and Operator Safety: — A worn or broken depth indicator spring can allow the indicator to drift or fail to return, leading to incorrect blade depth settings and potential blade damage or unsafe cut conditions.
The depth indicator extension spring provides the return tension that keeps the depth indicator arm in contact with its reference position on the saw's depth adjustment mechanism. When the operator sets blade depth, this spring ensures the indicator responds accurately and snaps back to position when released. If the spring stretches, fatigues, or breaks, the depth indicator becomes loose or unresponsive — making it difficult to set consistent cut depths and increasing the risk of over-cutting or blade contact with unintended material.
Part Details
| Part Number | 565004 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Depth Indicator Extension Spring |
Compatibility & Fitment
| Name | Model |
|---|---|
| MQ Pavement Saws | SP303526 |
| MQ Pavement Saws | SP605720 |
| MQ Pavement Saws | SP605730 |
| MQ Pavement Saws | SP4 |
| MQ Pavement Saws | SP303516 |
| MQ Pavement Saws | SP303520 |
| MQ Pavement Saws | SP303530 |
| MQ Pavement Saws | SP605716 |
| MQ Pavement Saws | SP605726 |
| MQ Pavement Saws | SP605736 |
| MQ Pavement Saws | SP6457 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
