The Multiquip CD101523 Field is a genuine OEM component designed for Core Drills equipment. Sourced directly from Multiquip, this part meets the exact specifications of the original component installed at the factory. Confirm your model against the fitment data before ordering to ensure a correct match for your Core Drills unit.
Key Features
- Genuine OEM Electromagnetic Specification — wound and rated to the original electrical output spec, ensuring correct field strength and motor response on Core Drills equipment.
- Direct-Fit Installation — matches the original mounting configuration and terminal connections, dropping into place without rework or adaptation.
- Confirmed Core Drills Fitment — verified for compatibility with Core Drills models; always cross-reference part number CD101523 against your unit's parts list.
- Sustained Motor Output — a properly functioning field winding maintains consistent torque and drilling power; a degraded field causes overheating, loss of power, and motor failure.
- Electrical Integrity — OEM winding insulation grade and wire gauge reduce the risk of shorts, ground faults, or thermal breakdown under continuous load.
The field winding is a core electrical component of a motor or generator assembly. It produces the magnetic field that interacts with the armature to generate torque or electrical output, depending on the application. When the field winding degrades — through heat damage, insulation breakdown, or physical wear — the motor loses power output, runs inefficiently, or fails to start altogether, making timely replacement essential to keeping the machine operational.
Part Details
| Part Number | CD101523 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Field |
Compatibility & Fitment
| Name | Model |
|---|---|
| Core Drills | CDM1H |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
