The Multiquip D1135000002 Armature Assembly is a genuine OEM component designed for the GAW180HE, GAW180HEA, and GAW180HE1 gasoline arc welder/generator units. As a direct Multiquip OEM part, the D1135000002 is manufactured to the same specifications as the original, ensuring a correct fit and consistent electrical output in the field. This assembly is confirmed compatible with the GAW180HE series, making it a straightforward service replacement when the original armature reaches the end of its service life. DHS Equipment supplies this part direct from the Multiquip OEM supply chain, so you receive an authentic component backed by the manufacturer.
Key Features
- Genuine OEM Winding Spec: — Wound to the original electrical resistance and output tolerances required by the GAW180HE series — no guesswork on voltage or amperage compliance.
- Direct-Fit Replacement: — Engineered to seat and connect exactly as the original armature does, with matching shaft dimensions and commutator geometry for a clean installation.
- Confirmed GAW180HE Series Fitment: — Verified for the GAW180HE, GAW180HEA, and GAW180HE1 gasoline arc welder/generator models.
- Consistent Arc and Power Output: — A properly functioning armature maintains steady current generation, which is critical for stable welding arc quality and clean generator output on the job.
- Electrical Safety Compliance: — Correct armature construction ensures proper insulation integrity and balanced rotation, reducing the risk of electrical faults in a combined welder/generator application.
- Authentic Multiquip OEM Part: — Sourced directly through the Multiquip OEM parts supply chain and sold by authorized distributor DHS Equipment.
The armature is the rotating core of the generator/welder's electrical system. It spins within the stator's magnetic field to produce the electrical current that powers both the welding arc and any auxiliary outlets on the machine. When an armature wears out or fails — through worn commutator segments, shorted windings, or physical damage — the machine will produce weak, unstable output or no electrical output at all, making welding impossible and potentially damaging connected equipment. Replacing the armature with a correct OEM assembly restores full rated output and stable arc performance.
For questions about fitment or to confirm compatibility with your specific unit, contact the DHS Equipment parts team before ordering.
Part Details
| Part Number | D1135000002 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Armature Assembly |
Compatibility & Fitment
| Name | Model |
|---|---|
| Welders | GAW180HE |
| Welders | GAW180HEA |
| Welders | GAW180HE1 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
