Multiquip EM514204 Splash Plate

The Multiquip EM514204 is a genuine OEM Splash Plate designed for hydraulic-driven concrete pump models including the LS300, LS400, LS500, LS600, LS60TD, LS40D, LS40TD, LS50TD, LS600P, LS300P, LS300G, and LS300GK. As a direct OEM replacement, this part is sourced from Multiquip to match the original component specification exactly, ensuring a straight swap with no guesswork on compatibility. Confirm your model code against the fitment list above before ordering to make sure EM514204 is the correct splash plate for your machine.

Key Features

• OEM-Matched Material Construction — Manufactured to the same material and dimensional tolerances as the original, ensuring the plate withstands the abrasive concrete slurry environment inside the pump hopper.
• Direct Drop-In Replacement — Engineered to mount in the same position and orientation as the factory part, allowing straightforward installation without custom fitting or modification.
• Broad LS-Series Compatibility — Fits LS300, LS400, LS500, LS600, LS60TD, LS40D, LS40TD, LS50TD, LS600P, LS300P, LS300G, and LS300GK hydraulic concrete pump models.
• Protects Pump Hopper Integrity — Deflects concrete mix away from critical structural and mechanical components, preserving the hopper and surrounding hardware against premature wear.
• Genuine Multiquip OEM Part — Sourced directly from Multiquip, this is the same splash plate supplied on new machines — not a generic substitute.

The splash plate is positioned inside the concrete pump's hopper, where it deflects the incoming concrete mix and controls the flow of material toward the pump cylinders. By directing the concrete slurry away from sensitive mechanical surfaces, it reduces impact wear on the hopper walls and internal components during continuous pumping operation. When a splash plate becomes cracked, worn, or missing, concrete can reach areas of the hopper it was never intended to contact, accelerating wear on surrounding hardware and potentially disrupting the consistent material feed the pump cylinders depend on.

For technical questions or help confirming fitment, contact the DHS Equipment team before placing your order.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
