The Multiquip RB252734 Inside Side Guide Plate (Right and Left) is a genuine OEM component designed for the JB series rebar benders, including the JB5090, JB5135, JB7090, JB7135, JB8090, JB9180, JB11090, and JPU1 models. As an authorized Multiquip replacement part, the part is manufactured to the same standards as the original, ensuring a direct drop-in fit with no guesswork. This guide plate set covers both the right and left sides, so a single part number addresses the complete inside side guide plate requirement. Keeping this component in good condition is essential to consistent, accurate bending performance on the jobsite.
Key Features
- Genuine OEM Construction: — Manufactured to Multiquip's original material and dimensional specifications, ensuring the guide plate seats and functions exactly as the factory-installed part.
- Right and Left Pair Included: — A single part number covers both the right-hand and left-hand inside side guide plates, simplifying the ordering process and keeping your replacement complete.
- Direct Fitment Across the JB Rebar Bender Series: — Confirmed compatible with JB5090, JB5135, JB7090, JB7135, JB8090, JB9180, JB11090, and JPU1 rebar benders.
- Accurate Bend Guidance: — The inside side guide plate channels rebar through the bending arc cleanly; a worn or damaged plate leads to rebar drift, imprecise bend angles, and increased operator effort.
- Safety-Critical Fit: — Properly seated guide plates keep rebar positively controlled during the bend cycle, reducing the risk of workpiece kickout or misalignment under load.
The inside side guide plates are the contact surfaces that direct and constrain the rebar as it moves through the bending head of a JB series rebar bender. By holding the bar firmly in the correct lateral position, these plates ensure each bend is made at the intended angle and radius. When the guide plates are cracked, excessively worn, or missing, the rebar can shift during the bend cycle — producing out-of-spec bends, placing extra stress on surrounding components, and creating a potential safety hazard for the operator.
For fitment questions or to confirm this part is correct for your specific serial number, contact the DHS Equipment team directly.
Part Details
| Part Number | RB252734 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Inside Side Guide Plate (Right and Left) |
Compatibility & Fitment
| Name | Model |
|---|---|
| Rebar Benders | JB7135 |
| Rebar Benders | JB8090 |
| Rebar Benders | JB9180 |
| Rebar Benders | JB11090 |
| Rebar Benders | JPU1 |
| Rebar Benders | JB5135 |
| Rebar Benders | JB5090 |
| Rebar Benders | JB7090 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
Why Buy From DHS Equipment
Every part is verified against the manufacturer's part number before it ships, so what you order is what arrives. We carry parts from leading OEM brands and our own DHS Quality Parts line of professional aftermarket components. Need help finding the right part? Our team is available to confirm compatibility whenever you need it. Orders are processed fast to keep your jobs on track. We don't just sell parts. We keep you jobsite ready.
Questions? Contact our team at [email protected] or 866-611-9369 — DHS Equipment is here to help you maintain peak performance.
