The Multiquip TS80011 Bracket Belt Guard TP/TS-1020 is a genuine OEM component designed for the TS1020 tile saw. This bracket secures the belt guard housing in the correct position, maintaining the integrity of the blade drive system and keeping the operator protected during cutting operations. As a direct OEM replacement sourced through Multiquip's authorized parts channel, the part is built to the same specifications as the original part installed at the factory, ensuring a seamless fit on TS1020 equipment.
Key Features
- OEM-Matched Bracket Construction — Manufactured to the same structural specifications as the original, ensuring the belt guard seats and mounts correctly without play or misalignment.
- Direct Bolt-On Installation — Designed to align with existing mounting points on the TS1020, so replacement is straightforward with standard tools.
- TS1020 Tile Saw Fitment — Confirmed compatibility with the Multiquip TS1020, eliminating guesswork when ordering a replacement bracket.
- Protects Belt Drive Integrity — Holds the guard securely in place so the drive belt runs in a clean, shielded path — a damaged or missing bracket can allow guard movement that accelerates belt wear.
- Operator Safety Function — The belt guard bracket is a safety-critical mount; a failed or bent bracket can allow the guard to shift, exposing the drive belt during operation.
The belt guard bracket on the TS1020 tile saw holds the protective guard enclosure firmly over the drive belt and pulley system. This keeps the belt properly shielded from debris, water, and accidental contact — all common conditions in tile cutting environments. When the bracket is bent, cracked, or missing, the guard can shift or detach, exposing moving components and increasing the risk of belt damage or operator injury.
Part Details
| Part Number | TS80011 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Bracket Belt Guard TP/TS-1020 |
Compatibility & Fitment
| Name | Model |
|---|---|
| TS1020 | TS1020 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
