The Multiquip 0013806010 Flange Bolt M6X10 is a genuine OEM fastener designed for GBX series balloon systems and towable towers, including GBX12S, GBX12SK, GBX24S, GBX24B, GBX24BK, and related GBX platform equipment. As an authentic Multiquip OEM component, it is manufactured to the exact thread pitch, head diameter, and shank length required for a correct, secure installation. Sourcing the correct OEM fastener matters — an improperly specified bolt can lead to loose assemblies, misalignment, or structural failure in field conditions. Confirm your model code against the fitment list before ordering to ensure this is the right hardware for your machine.
Key Features
- OEM Thread Specification: — M6x10 metric sizing matches the exact thread pitch and engagement depth specified for GBX series assemblies, ensuring a secure and properly torqued connection.
- Integrated Flange Design: — The built-in flange distributes clamping load evenly across the mating surface, eliminating the need for a separate washer and maintaining consistent joint integrity.
- Direct-Fit for GBX Series Equipment: — Compatible with GBX12S, GBX12SK, GBX24S, GBX24B, and GBX24BK balloon systems and towable towers for a straightforward, tool-matched installation.
- Structural Fastener Integrity: — Using the correct OEM bolt grade prevents joint fatigue and fastener shear in high-vibration or load-bearing positions common in balloon lighting equipment.
- Electrical and Structural Safety Relevance: — In balloon light tower assemblies, fastener integrity directly affects housing stability and safe operation of the lighting system under field conditions.
A flange bolt combines the function of a standard bolt and a washer into a single fastener, with a wide bearing surface integrated beneath the bolt head. This design spreads clamping force across a broader contact area, reducing the risk of surface damage and maintaining joint tension over time. In balloon lighting systems and towable tower assemblies, where panels, housings, and structural brackets must remain firmly secured during transport and operation, using the correct specified fastener is essential to safe and reliable performance.
Part Details
| Part Number | 0013806010 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Flange Bolt M6X10 |
Compatibility & Fitment
| Name | Model |
|---|---|
| Balloon Systems | GBX |
| Balloon Systems | GBX24S |
| Balloon Systems | GBX24B |
| Balloon Systems | GBX12S |
| Balloon Systems | GBX12SK |
| Balloon Systems | GBX24BK |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
