Multiquip 054-065-00 Brake Cylinder RS Uni-Servo

The Multiquip 054-065-00 is a genuine OEM Brake Cylinder RS Uni-Servo designed for Multiquip trailer models including TRLR45H, TRLR45E, TRLR502XFH, TRLR502XFE, TRLRSG1600XFH, and TRLRSG1600XFE. As a direct OEM replacement sourced through Multiquip's authorized parts network, this cylinder meets the exact specifications of the original unit installed at the factory. Keeping your trailer's braking system equipped with the correct OEM component is critical for both operator safety and regulatory compliance on jobsites and public roads. DHS Equipment stocks this part to get your trailer back in service quickly and correctly.

Key Features

• OEM Brake-Grade Quality — Manufactured to the original hydraulic pressure tolerances required for uni-servo drum brake operation, ensuring consistent and proportional braking force.
• Direct-Fit Replacement — Engineered to install into the existing brake assembly mounting position on compatible Multiquip trailer axles without alteration to hardware or brake lines.
• Broad Trailer Compatibility — Confirmed fitment across TRLR45H, TRLR45E, TRLR502XFH, TRLR502XFE, TRLRSG1600XFH, and TRLRSG1600XFE models.
• Hydraulic Integrity Under Load — Correct cylinder bore sizing maintains proper fluid displacement, delivering the stopping power these heavy-duty equipment trailers demand.
• Safety-Critical Component — A worn or leaking brake cylinder compromises hydraulic pressure and braking response; replacing with a genuine OEM unit restores the system to its original rated performance and meets trailer brake compliance requirements.

The brake cylinder in a uni-servo drum brake system converts hydraulic pressure from the master cylinder into mechanical force that pushes the brake shoe against the drum to slow or stop the trailer. In a uni-servo configuration, this action is self-energizing — the primary shoe amplifies force to the secondary shoe, making the cylinder's output and internal seal integrity especially important. When the cylinder wears, develops an internal leak, or loses pressure, braking force becomes inconsistent or fails entirely, creating a serious safety hazard when towing heavy equipment. Replacing the part restores full hydraulic function to the brake assembly and returns the trailer to safe operating condition.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
