The Multiquip 3031101201 is a genuine OEM Stator 1 Phase 2 Pole 90 x 47 x 40L designed for ST1 and ST1F series submersible pump units. As a direct Multiquip OEM component, this stator is manufactured to the exact electrical and dimensional specifications of the original part, ensuring correct motor operation without adaptation. Verified fitment covers the ST1 and ST1F submersible pump models, making part selection straightforward for operators and service technicians alike. DHS Equipment supplies this part direct from the Multiquip OEM catalog so you receive the correct component every time.
Key Features
- OEM-Matched Winding Specification — Single-phase, 2-pole configuration wound to the original resistance and output spec, ensuring proper motor torque and amperage draw in ST1 series pumps.
- Exact Dimensional Fit — 90 x 47 x 40L profile matches the original stator housing bore, allowing direct drop-in installation with no machining or shimming required.
- Confirmed ST1 and ST1F Fitment — Sourced and verified for Multiquip ST1 and ST1F submersible pump models, so you can order with confidence.
- Restores Full Motor Output — A worn or failed stator causes the pump motor to run hot, draw excessive current, or fail to start; replacing with this OEM part brings motor performance back to original operating condition.
- Electrical Safety Compliance — Genuine OEM winding construction maintains proper insulation ratings for a submersible motor environment, where electrical integrity directly affects operator safety.
The stator is the stationary winding assembly inside the electric motor that generates the rotating magnetic field required to spin the rotor and drive the pump impeller. In a submersible pump application, the stator must maintain consistent winding resistance and insulation integrity while operating in a sealed, moisture-adjacent environment. When a stator degrades — through heat damage, winding failure, or insulation breakdown — the motor loses torque, draws irregular current, or stops running entirely, taking the pump out of service until the stator is replaced.
Part Details
| Part Number | 3031101201 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | Stator 1 Phase 2 Pole 90 x 47 x 40L |
Compatibility & Fitment
| Name | Model |
|---|---|
| Submersible Pumps | ST1 |
| Submersible Pumps | ST1F |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
Why Buy From DHS Equipment
Every part is verified against the manufacturer's part number before it ships, so what you order is what arrives. We carry parts from leading OEM brands and our own DHS Quality Parts line of professional aftermarket components. Need help finding the right part? Our team is available to confirm compatibility whenever you need it. Orders are processed fast to keep your jobs on track. We don't just sell parts. We keep you jobsite ready.
Questions? Contact our team at [email protected] or 866-611-9369 — DHS Equipment is here to help you maintain peak performance.
