The Multiquip A3154000003 End Bracket Assembly is a genuine OEM component designed for GAC3.6HR, GAC6HR, GAC6HRS, GA6HR, GA6HRS, and GA6HRSNC2 series gasoline-powered generators. As a direct OEM replacement, it is manufactured to the same specifications as the original part, ensuring a consistent, accurate fit within the alternator assembly. Sourced directly through authorized Multiquip distribution, this bracket is the correct factory-spec choice for keeping your generator running as designed. DHS Equipment stocks this part and can help confirm fitment for your specific unit.
Key Features
- Genuine OEM Construction — Manufactured to the same tolerances and material spec as the original, ensuring the bracket seats and aligns correctly within the alternator end housing.
- Drop-In Alternator Fit — Engineered to match the original mounting points and bolt pattern for the GA and GAC series generator alternators, with no rework required on the housing.
- Broad GA/GAC Series Coverage — Confirmed fitment for GAC3.6HR, GAC6HR, GAC6HRS, GA6HR, GA6HRS, and GA6HRSNC2 models under a single part number.
- Structural Integrity for Alternator Alignment — A worn or damaged end bracket can cause rotor misalignment, bearing wear, and voltage irregularities; replacing it restores proper alternator geometry and output stability.
- Electrical Safety Relevance — Correct end bracket fitment is essential to maintaining proper rotor clearance and preventing contact between rotating and stationary alternator components.
The end bracket assembly serves as the structural endcap of the alternator, housing the rear bearing and maintaining precise alignment between the rotor and stator. It keeps the rotating components centered within the alternator casing so that air gap tolerances remain consistent during operation. When an end bracket cracks, warps, or loses its bearing seat integrity, rotor contact, vibration, and loss of electrical output can follow — making timely replacement critical to generator reliability.
Part Details
| Part Number | A3154000003 |
|---|---|
| Brand | Multiquip |
| Part Type | Genuine OEM |
| Description | End Bracket Assembly |
Compatibility & Fitment
| Name | Model |
|---|---|
| Gasoline Powered Generators | GAC3.6HR |
| Gasoline Powered Generators | GAC6HR |
| Gasoline Powered Generators | GAC6HRS |
| Gasoline Powered Generators | GA6HR/GA6HRS/GA6HRSNC2 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
