Multiquip CD290084 Angle Adjust Tube 1

The Multiquip CD290084 Angle Adjust Tube 1 is a genuine OEM component designed for the DM15A9C Drill Rig Stand and CDM2CSA Core Drill series. Sourced directly from Multiquip, this part meets the same specifications as the original, ensuring a correct, consistent installation without guesswork. If you are servicing or rebuilding the angle adjustment assembly on your DM15A9C or CDM2CSA, this is the exact tube specified for that system.

Key Features

• Genuine OEM Construction — Manufactured to Multiquip's original design tolerances for the angle adjustment system, not an approximation of the original part.
• Direct Installation Fit — Matches the original tube geometry and connection points, dropping directly into the angle adjust assembly on compatible drill rigs.
• Confirmed Fitment — Verified for the DM15A9C Drill Rig Stand and CDM2CSA Core Drill series.
• Positional Accuracy Under Load — A correctly functioning angle adjust tube maintains the drill head at the set angle during operation; a worn or damaged tube allows unwanted movement that compromises bore alignment.
• Structural Integrity for Drilling Applications — Core drilling places continuous lateral and axial stress on angle adjustment hardware; this OEM tube is built to handle those operating loads without deformation.

The angle adjust tube is a structural component within the drill rig's angle adjustment mechanism, allowing the operator to set and hold the drill head at a precise working angle relative to the surface. It transmits and resists the mechanical forces generated during core drilling, keeping the drill positioned accurately throughout the cut. When this tube is damaged, bent, or worn, the angle setting becomes unstable, leading to misaligned bores, increased bit wear, and potential damage to surrounding hardware.

For questions about fitment or to confirm this is the correct part for your machine, contact the DHS Equipment team before ordering.
