Multiquip EE41587 Wireway Lay-In Type 12 Elbow 90 Deg Ins

The Multiquip EE41587 Wireway Lay-In Type 12 Elbow 90 Deg Ins is a genuine OEM component designed for TYPE-12 series equipment. This insulated 90-degree elbow section integrates directly into the lay-in wireway system, providing a clean, direction-changing pathway for routed electrical conductors. Sourced directly through Multiquip's OEM supply chain, EE41587 is the correct replacement when the existing elbow is damaged, cracked, or no longer providing adequate cable protection.

Key Features

• OEM Insulated Construction — The insulated (Ins) rating on this Type 12 elbow ensures conductors are protected from incidental contact and moisture ingress typical in enclosed industrial enclosure environments.
• Lay-In Design for Easy Wire Routing — The open lay-in channel style allows wires to be placed directly into the wireway without threading, speeding up installation and rewiring tasks significantly.
• 90-Degree Direction Change — Purpose-built elbow geometry delivers a clean right-angle transition within the wireway run, maintaining consistent cable bend radius and preventing conductor stress at corners.
• Direct Replacement for TYPE-12 Wireway Systems — this part is matched to the TYPE-12 wireway configuration, ensuring the elbow seats and connects flush with existing straight sections without shimming or modification.
• Genuine Multiquip OEM Part — Manufactured to the same specification as the original component, this part maintains the integrity of the enclosure's electrical routing system as designed.

A lay-in wireway elbow is the directional fitting that allows an enclosed cable management channel to change course at a 90-degree angle while keeping conductors contained and protected. In Type 12 enclosures — which are rated to guard against dust, dirt, and dripping non-corrosive liquids — the elbow section is a critical link in maintaining that protection at every bend in the routing path. When an elbow section cracks, warps, or loses its insulated lining, conductors at that junction become exposed to contamination and physical damage, which can lead to shorts, failed inspections, or unplanned electrical downtime.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
