The Husqvarna 506396101 Nozzle Assembly is a genuine OEM component designed for the K760 and K750 power cutters. As a direct OEM replacement, this assembly is built to Husqvarna's exact specifications, ensuring the correct fuel-to-air delivery that these power cutters depend on for consistent starts and steady throttle response. DHS Equipment supplies this part to help keep your equipment running at full capability.
Key Features
- OEM Fuel Circuit Accuracy — Manufactured to Husqvarna's exact nozzle geometry and flow specifications, ensuring the correct fuel metering that the carburetor system requires.
- Direct-Fit Replacement — Engineered to seat and connect exactly as the original assembly, allowing a straightforward swap without modification to carburetor mounting or fuel line routing.
- Confirmed Fitment for K760 and K750 — Verified compatibility with both K760 and K750 power cutters, so you can order with confidence knowing this assembly matches your machine.
- Consistent Throttle Response — A correctly functioning nozzle assembly maintains steady fuel atomization across the RPM range, supporting clean acceleration and full cutting power under load.
- Genuine OEM Part Number 506396101 — Cross-reference part number 506396101 against your parts diagram to confirm the exact position and application before installation.
The nozzle assembly is a critical component within the carburetor circuit, responsible for atomizing fuel and delivering it in the correct quantity to the engine at each throttle position. When the nozzle becomes worn, blocked, or damaged, the engine may struggle to start, run lean, or lose power under cutting load — all of which reduce productivity and can stress other engine components. Replacing this assembly with a genuine OEM unit restores the precise fuel delivery the K760 and K750 power cutters were designed to operate on.
Part Details
| Part Number | 506396101 |
|---|---|
| Brand | Husqvarna |
| Part Type | Genuine OEM |
| Description | Nozzle Assembly |
Compatibility & Fitment
| Name | Model |
|---|---|
| Power Cutter | K760 |
| Power Cutter | K750 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
