The Genie 13317GT is a genuine OEM Boom Riser Pivot Pin, 15.625 built for Genie Z-30/20HD and Z-30/20 articulating boom lifts. As an authentic Genie OEM component, this pin is manufactured to the same specifications as the original part, ensuring correct fit and function without rework or modification. Cross-reference part number 13317GT against your machine's parts manual to confirm it is the right pin for your specific unit before ordering. DHS Equipment stocks genuine Genie OEM parts so you can get the right component and get back to work.
Key Features
- Genuine OEM Construction — Manufactured to Genie's exact dimensional and material standards for a Boom Riser Pivot Pin, ensuring the correct load-bearing grade and surface finish for this application.
- Exact-Fit Replacement — Matches the original 15.625-inch pin geometry, dropping directly into the boom riser pivot point with no machining or adaptation.
- Confirmed Fitment — Designed for Genie Z-30/20HD and Z-30/20 articulating boom lifts; verify part number 13317GT against your serial number and parts manual before ordering.
- Structural Integrity at the Pivot — A sound pivot pin maintains precise, controlled articulation of the boom riser. A worn or damaged pin introduces play at the joint, leading to imprecise boom movement and accelerated wear on surrounding components.
- Safety-Critical Component — The boom riser pivot pin is a structural hinge point on an aerial lift. Using the correct OEM-specification pin helps maintain the structural integrity the machine's design depends on for safe operation at height.
A boom riser pivot pin acts as the hinge that connects the riser section of an articulating boom to its mating structure, allowing the boom to articulate through its designed range of motion while bearing the loads placed on it during operation. When this pin wears, corrodes, or becomes damaged, it can introduce unwanted movement or slop into the joint, which affects boom positioning accuracy and places additional stress on the surrounding bores and hardware. Replacing a worn pin promptly with the correct OEM part restores the tight, controlled movement the boom assembly requires and helps protect the integrity of the components around it.
Part Details
| Part Number | 13317GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Boom Riser Pivot Pin, 15.625 |
Compatibility & Fitment
| Name | Model |
|---|---|
| Z-30/20HD | Z-30/20HD |
| Z-30/20 | Z-30/20 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
