The Genie 13366GT is a genuine OEM Pin, 1.25 Dia. x 7.25 Lg, 2 Hole built for the Z-30/20HD and Z-30/20 articulating boom lifts. As a direct OEM replacement, this pin is manufactured to the same dimensional and material standards as the original, ensuring a correct fit in the joint or pivot point it serves. Confirm part number 13366GT against your machine's parts manual to verify it is the right pin for your serial number range before ordering.
Key Features
- Genuine OEM Dimensional Conformity — Manufactured to exact diameter (1.25 in.) and length (7.25 in.) specifications, with two holes positioned to match the original mounting arrangement.
- Direct OEM Replacement — Sourced directly from Genie, this pin installs in place of the original without rework or modification to the receiving bores or retaining hardware.
- Correct Fitment for Z-30/20 Articulating Booms — Specified for the Z-30/20HD and Z-30/20, covering both standard and heavy-duty variants of this articulating boom lift model.
- Structural Integrity at the Joint — A pin at the correct diameter and hardness carries shear loads across the joint without deflection. An undersized, worn, or incorrect pin introduces play that accelerates wear on surrounding components.
- Safety-Critical Component — Pivot and hinge pins are load-bearing fasteners on aerial lifts. Using the correct OEM part maintains the structural integrity the machine's design depends on for safe operation at height.
A pivot pin like this one connects two structural members at a hinge or joint, allowing controlled articulation while transferring shear loads between them. The two-hole configuration accepts retaining hardware — such as cotter pins or clips — that locks the pin in position and prevents it from walking out under load or vibration. When a pin wears out of tolerance or loses its retaining points, joint play increases, accelerating wear on the surrounding bores and compromising the precision of boom movement. Replacing a worn pin promptly with the correct OEM part restores tight, predictable motion to the joint it serves.
Part Details
| Part Number | 13366GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Pin, 1.25 Dia. x 7.25 Lg, 2 Hole |
Compatibility & Fitment
| Name | Model |
|---|---|
| Z-30/20HD | Z-30/20HD |
| Z-30/20 | Z-30/20 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
