The Genie 824074GT Hex Head Cap Screw is a genuine OEM fastener built for Genie SX telescopic boom lifts and Z articulating boom lifts. Sourced directly from Genie, this screw is manufactured to the exact dimensional and material specifications of the original hardware — no improvised substitutes, no guesswork on thread pitch or finish. It fits a wide range of Genie boom lifts including the SX-105 XC, SX-125 XC, Z-45/25, Z-45/25J DC, Z-45/25J Bi-Energy, Z-34/22 series, Z-40/23N, Z-30/20 N, and Z-30/20N RJ, among others. Cross-reference part number 824074GT against your machine's parts manual to confirm it is the correct item for your specific unit before ordering.
Key Features
- Genuine OEM Material and Dimensional Conformity — Zinc-coated alloy construction (ZAG finish) meets the original thread form, grade, and corrosion-resistance spec for this application.
- Exact Thread and Length Match — 1-8 thread pitch and correct shank length ensure the fastener draws up and seats the way the original did, without modification to surrounding hardware.
- Broad Boom Lift Fitment — Fits Genie SX super-telescopic booms and a wide range of Z articulating booms, including Bi-Energy, DC, N, IC, and RJ variants.
- Structural Integrity at the Joint — A fastener installed at the correct grade and finish holds clamping force under load and vibration; an incorrect or worn substitute can back out or fail to maintain the joint, affecting the structural integrity of the assembly it secures.
- Direct OEM Replacement — As a genuine Genie part, this screw ships with confidence that the specification matches what the machine was built with, so the replacement restores the connection as designed.
A hex head cap screw is a structural fastener used to clamp and secure components within an assembly. The hex head allows a wrench or socket to apply the correct torque, drawing mating surfaces together and holding them under load. The ZAG (zinc alloy galvanized) finish provides corrosion resistance, which is important on boom lift structures exposed to outdoor conditions. When a fastener of the wrong grade, thread, or length is used — or when an original screw is stripped, corroded, or missing — the joint it was designed to secure can loosen under machine operation, which is why replacing it with the correct OEM part matters.
Part Details
| Part Number | 824074GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Hex Head Cap Screw, 1-8X3,8, ZAG |
Compatibility & Fitment
| Name | Model |
|---|---|
| SX-105 XC | SX-105 XC |
| SX-125 XC | SX-125 XC |
| Z-30/20 N | Z-30/20 N |
| Z-30/20N RJ | Z-30/20N RJ |
| Z-40/23N | Z-40/23N |
| Z-40/23N RJ | Z-40/23N RJ |
| Z-45/25 | Z-45/25 |
| Z-45/25J DC | Z-45/25J DC |
| Z-45/25J Bi-Energy | Z-45/25J Bi-Energy |
| Z-34/22 Bi-Energy | Z-34/22 Bi-Energy |
| Z-34/22 DC | Z-34/22 DC |
| Z-34/22 N | Z-34/22 N |
| Z-34/22 IC | Z-34/22 IC |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
