The Genie 49401GT is a genuine OEM Hex Head Cap Screw, M8 x 100, built for Genie GS scissor lifts, TMZ trailer-mounted articulating booms, and Z articulating booms including the Z-60/34 and Z-80/60. As a direct OEM replacement, this screw is manufactured to the exact thread pitch, grade, and dimensional spec Genie specifies for these machines. Cross-reference part number 49401GT against your machine's parts manual to confirm this is the correct fastener for your application before ordering.
Key Features
- OEM-Grade Fastener Spec — Manufactured to the precise M8 x 100 thread and material grade Genie requires, ensuring consistent torque retention and clamping load at the installation point.
- Exact Dimensional Fit — Correct thread pitch, shank length, and hex drive size allow this screw to seat and torque to spec without modification or adjustment.
- Broad Genie Fitment — Confirmed for the GS-3384 scissor lift, TMZ-34/19 and TMZ-50/30 trailer booms, and Z-60/34 and Z-80/60 articulating booms.
- Structural Integrity — A correctly specified fastener holds assemblies securely under the dynamic loads these machines encounter in daily operation; an incorrect or worn screw can compromise joint integrity.
- Genuine OEM Part — Sourced directly through the Genie OEM supply chain, so the grade, finish, and dimensions match what came off the assembly line.
A hex head cap screw is a fully threaded or partially threaded fastener used to clamp and secure structural and mechanical assemblies on the machine. The M8 x 100 designation identifies the metric thread diameter and overall length, both of which are critical — a fastener that is too short will not develop full thread engagement, while one of the wrong grade may stretch or fail under load. Using the correct OEM fastener at each joint ensures the assembly is held to the designed clamping force and remains secure through the vibration and movement typical of aerial lift and boom operation.
Part Details
| Part Number | 49401GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Hex Head Cap Screw, M8 x 100 |
Compatibility & Fitment
| Name | Models |
|---|---|
| GS-3384 | GS-3384 |
| TMZ-34/19 | TMZ-34/19 |
| TMZ-50/30 | TMZ-50/30 |
| Z-60/34 | Z-60/34 |
| Z-80/60 | Z-80/60 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
