The Genie 1256460GT Pan Head Machine Screw, 10-24x1 is a genuine OEM fastener built for a broad range of Genie equipment, including S and SX telescopic boom lifts, GS scissor lifts, Z and ZX articulating boom lifts, and GTH telehandlers. As a direct OEM replacement, this screw is manufactured to the exact thread pitch, head profile, and finish specification called out in the Genie parts manual. Cross-reference part number 1256460GT against your machine's parts manual to confirm it is the correct fastener for your application before ordering.
Key Features
- OEM Thread and Dimensional Accuracy — Manufactured to the exact 10-24 thread specification and 1-inch length, ensuring correct engagement and clamping load in every installation.
- ZAG Finish for Durability — The zinc-alloy-plated finish provides corrosion resistance suited to the demanding environments these machines operate in.
- Direct Drop-In Replacement — Matches the original pan head profile and drive specification, so the screw installs straight into existing hardware without rework or modification.
- Wide Equipment Compatibility — A single part number covers a broad cross-section of Genie S and SX booms, GS scissor lifts, Z and ZX articulating booms, and GTH telehandlers, making it a practical stocking fastener for mixed Genie fleets.
- Genuine Genie OEM Part — Sourced directly through the Genie OEM supply chain, so you can be confident this part meets the same material and dimensional standards as the hardware it replaces.
A pan head machine screw secures components by threading into a tapped hole or a mating nut, clamping parts together with controlled torque. The pan head profile distributes clamping load across a broad bearing surface, making it well suited to panel, bracket, and cover fastening applications. A stripped, corroded, or missing fastener compromises the integrity of the assembly it holds — replacing worn hardware with the correct OEM specification screw restores proper clamping and prevents movement or vibration damage to surrounding components.
Part Details
| Part Number | 1256460GT |
|---|---|
| Brand | Genie |
| Part Type | Genuine OEM |
| Description | Pan Head Machine Screw, 10-24x1, ZAG |
Compatibility & Fitment
| Name | Model |
|---|---|
| S-60 | S-60 |
| S-65 | S-65 |
| S-60X | S-60X |
| S-60 XC | S-60 XC |
| S-60 HC | S-60 HC |
| S-60 TRAX | S-60 TRAX |
| S-65 TRAX | S-65 TRAX |
| SX-150 | SX-150 |
| SX-180 | SX-180 |
| SX-135 XC | SX-135 XC |
| S-60 J | S-60 J |
| S-60 FE Hybrid | S-60 FE Hybrid |
| S-60 DC | S-60 DC |
| S-60 FE | S-60 FE |
| S-85 XC FE | S-85 XC FE |
| S-85 XC E | S-85 XC E |
| S-40 | S-40 |
| S-45 | S-45 |
| GS-1932 | GS-1932 |
| GS-2632 | GS-2632 |
| GS-3232 | GS-3232 |
| GS-2646 | GS-2646 |
| GS-3246 | GS-3246 |
| GS-4046 | GS-4046 |
| GS-3390 | GS-3390 |
| GS-4390 | GS-4390 |
| GS-5390 | GS-5390 |
| GTH-636 | GTH-636 |
| GTH-844 | GTH-844 |
| GTH-1056 | GTH-1056 |
| Z-135/70 | Z-135/70 |
| Z-51/30J | Z-51/30J |
| Z-45/25 | Z-45/25 |
| Z-45/25J IC Power | Z-45/25J IC Power |
| Z-45/25J DC | Z-45/25J DC |
| Z-45/25J Bi-Energy | Z-45/25J Bi-Energy |
| Z-62/40 | Z-62/40 |
| ZX-135/70 | ZX-135/70 |
| Z-80/60 | Z-80/60 |
| Z-45 XC | Z-45 XC |
| Z-60/37 DC | Z-60/37 DC |
| Z-60/37 FE Hybrid | Z-60/37 FE Hybrid |
| Z-45/25 IC | Z-45/25 IC |
| Z-60 DC | Z-60 DC |
| Z-60 FE Hybrid | Z-60 FE Hybrid |
| Z-45 FE Hybrid | Z-45 FE Hybrid |
| Z-45 DC | Z-45 DC |
| Z-60 FE | Z-60 FE |
| Z-45/25J IC | Z-45/25J IC |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
