The Wacker Neuson 5100003656 is a genuine OEM Belt Guide designed for the DPU6555 and DPU6055 series diesel reversible vibratory plate compactors, as well as the BPU5045A gasoline reversible vibratory plate. As a direct OEM replacement sourced through authorized Wacker Neuson channels, this Belt Guide is manufactured to the same specification as the original component installed at the factory. It is confirmed to fit a broad range of DPU6555 variants — including the He, Heh, Hec, Hes, Hecsh, Hesh, Hecs, Heap, Hehap, and corresponding US-market models — along with DPU6055 and BPU5045A units. Using part number 5100003656 ensures you are selecting the correct guide for your machine and avoiding costly mismatches.
Key Features
- Genuine OEM Construction: — Manufactured to the original dimensional tolerances that keep the drive belt properly aligned under continuous vibration and load cycling.
- Direct Drop-In Replacement: — Mounts in the same position as the original, using existing hardware points so installation stays straightforward.
- Broad DPU/BPU Compatibility: — Fits the full DPU6555 variant range, DPU6055 series, and BPU5045A reversible vibratory plates — one part number covering a wide equipment lineup.
- Protects Drive Belt Integrity: — Keeps the belt tracking correctly during operation; a missing or worn guide allows lateral belt movement that accelerates belt wear and can cause premature belt failure.
- Correct Fit for High-Vibration Environments: — Engineered to retain its position and geometry under the sustained vibration loads that reversible plate compactors generate during compaction cycles.
The belt guide is a positioning component that holds the drive belt on its correct path between the engine and the exciter housing on a reversible vibratory plate compactor. By constraining lateral movement of the belt, it prevents the belt from drifting off the pulley during the direction changes and load shifts that are characteristic of reversible plate operation. When the belt guide is cracked, broken, or missing entirely, the drive belt can walk off alignment, leading to rapid belt wear, loss of compaction force, and eventual belt breakage that takes the machine out of service.
Part Details
| Part Number | 5100003656 |
|---|---|
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Belt Guide |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| DPU6555Heh | DPU6555Heh | 5100009636 |
| DPU6555Hehap | DPU6555Hehap | 5100009638 |
| DPU6555 Hech | DPU6555 Hech | 5100009639 |
| DPU6555Heap | DPU6555Heap | 5100016943 |
| Reversible Vibratory Plate, 50 kN, 45cm/18in | BPU 5045A | 5000008545 |
| DPU6555Hech US | DPU6555Hech US | 5100009650, 5100062487 |
| DPU6555Hes | DPU6555Hes | 5100016941 |
| DPU6555He | DPU6555He | 5100016940 |
| DPU6555HEH US | DPU6555Heh US | 5100009637, 5100058447 |
| DPU6555Hecsh | DPU6555Hecsh | 5100015775 |
| DPU6555Hesh | DPU6555Hesh | 5100015774 |
| DPU6555Hecs | DPU6555Hecs | 5100016945 |
| DPU6555Hec | DPU6555Hec | 5100016944 |
| DPU 6555Hs | DPU 6555Hs | 5100015773 |
| DPU 6555H | DPU 6555H | 5100009651, 5000610355 |
| DPU6055-VIBROPLATE | DPU 6055He | 5000610053 |
| V.Plate DPU 6055Heap | DPU 6055 | 5000610049, 5000610050 |
| DPU6555Hechzf | DPU6555Hechzf | 5100021400 |
| DPU6055-VIBROPLATE | DPU 6055 WC | 5000610175 |
| Vibration Plate | DPU6555Hec US | 5100016946 |
| Vibration Plate | DPU6555He US | 5100016942 |
| Vibratory Plate DPU 6555Heap | DPU 6555Heap | 5000610356 |
| DPU6555Hech | DPU6555Hech | 5100051524 |
| DPU6555He-VIBROPLATE | DPU 6555He US | 5000610357 |
| Vibration Plate | DPU6555Hehapn | 5100079579 |
| Vibratory Plate DPU 6555He | DPU 6555He | 5000610354 |
| DPU6555Hec Reversible Vibratory Plate | DPU 6555Hec US | 5100004399 |
| Vibratory Plate | DPU 6555Hec | 5100004060 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
