The Wacker Neuson 5100005715 is a genuine OEM Bottom Switch designed for the DPU80, DPU90, and DPU110 series reversible vibratory plate compactors. As a direct OEM replacement, this switch is sourced and supplied to the same specification as the original component installed at the factory, ensuring correct electrical function and a direct drop-in fit. Fitment covers a wide range of DPU variants including Lec, Lem, Lekc, and rLec configurations across the 670, 770, 870, and 970 platform generations, including US-market models. If your DPU80, DPU90, or DPU110 compactor is showing operator control issues, the 5100005715 Bottom Switch is the verified OEM part to restore proper machine function.
Key Features
- Genuine OEM Electrical Specification — Manufactured to the exact switching threshold and contact rating required for DPU-series plate compactor control circuits, ensuring correct signal output every actuation.
- Direct Drop-In Replacement — Engineered to match the original mounting configuration and connector interface, so installation proceeds without modification to the harness or housing.
- Broad DPU Series Coverage — Compatible with DPU80, DPU90, and DPU110 models across Lec, Lem, Lekc, rLec, and rLem configurations, including 670, 770, 870, and 970 platform variants and US-market editions.
- Restores Operator Control Integrity — A worn or faulty bottom switch can cause unresponsive or erratic compactor behavior; replacing it with the correct OEM part returns crisp, dependable operator input response.
- Operational Safety Relevance — On reversible plate compactors, the bottom switch is part of the operator control system. Using the correct OEM-specified switch supports proper machine response and safe directional control.
The bottom switch on a DPU-series reversible plate compactor is an operator-interface component that registers input from the control handle and communicates it to the machine's directional or operational control system. When functioning correctly, it allows the operator to manage compactor movement and plate direction with confidence. If the switch becomes worn, contaminated, or fails, the compactor may become unresponsive to operator commands or behave erratically, compromising both productivity and safe operation on the worksite. Replacing a failed bottom switch promptly with a genuine OEM part like the Wacker Neuson 5100005715 ensures the machine responds exactly as designed.
Part Details
| Part Number | 5100005715 |
|---|---|
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Bottom Switch |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| DPU90Lec670 | DPU90Lec670 | 5100027534 |
| DPU90Lec770 | DPU90Lec770 | 5100027536 |
| DPU80Lec770 | DPU80Lec770 | 5100026787 |
| DPU110Lec970 | DPU110Lec970 | 5100027035 |
| DPU110Lec870 | DPU110Lec870 | 5100026869 |
| DPU80Lec670 | DPU80Lec670 | 5100027032 |
| DPU110Lem970 | DPU110Lem970 | 5100024696 |
| DPU80rLec670 | DPU80rLec670 | 5100027033 |
| DPU80Lem770 | DPU80Lem770 | 5100018444 |
| DPU110Lec970 US | DPU110Lec970 US | 5100026784 |
| DPU90Lec770 US | DPU90Lec770 US | 5100028357 |
| DPU110Lem870 | DPU110Lem870 | 5100018445 |
| DPU80Lem670 | DPU80Lem670 | 5100024695 |
| DPU80rLec770 | DPU80rLec770 | 5100027034 |
| DPU90Lem770 | DPU90Lem770 | 5100024731 |
| DPU110rLec970 | DPU110rLec970 | 5100027036 |
| DPU90Lem770 US | DPU90Lem770 US | 5100024732 |
| DPU110rLec870 | DPU110rLec870 | 5100027077 |
| DPU80rLem670 | DPU80rLem670 | 5100024697 |
| DPU90rLec770 US | DPU90rLec770 US | 5100028359 |
| DPU80rLem770 | DPU80rLem770 | 5100024698 |
| DPU110Lem970 US | DPU110Lem970 US | 5100024730 |
| DPU110rLem970 | DPU110rLem970 | 5100024699 |
| DPU90rLem770 | DPU90rLem770 US | 5100028358 |
| DPU110rLec970 US | DPU110rLec970 US | 5100026786 |
| DPU110rLem870 | DPU110rLem870 | 5100026697 |
| DPU110rLem970 US | DPU110rLem970 US | 5100026785 |
| DPU110Lekc970 | DPU110Lekc970 | 5100034515 |
| Vibration Plate DPU 80-110(r) KMAT | DPU 80/110 KMAT | 5100016604 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
