The Wacker Neuson Red Bellows Ral 3020 is a genuine OEM bellows designed for BS60, BS70, BS600, BS700, DS70, and DS720 series vibratory rammers. As a direct OEM replacement, this part is produced to the same specifications as the original component fitted at the factory, ensuring a correct installation with no guesswork. Fitment covers a broad range of two-cycle, four-cycle, and diesel rammer configurations equipped with the 280mm/11in shoe. Keep a spare on hand — the bellows is a high-wear item exposed to continuous impact and flex during every compaction cycle.
Key Features
- OEM-Grade Rubber Compound: — Molded from the same material specification as the original, delivering the flex strength and tear resistance this high-cycle application demands.
- Color-Coded RAL 3020 Red: — The correct RAL 3020 red finish ensures visual identification is maintained during inspection and servicing, matching original machine aesthetics.
- Drop-In Replacement: — Engineered to the same mounting dimensions as the factory part, allowing direct installation on 280mm/11in shoe-equipped rammer configurations.
- Wide Rammer Family Coverage: — Confirmed fitment across BS60-2, BS60-4s, BS70-2, BS600, BS700, DS70, and DS720 models — covering both gasoline and diesel vibratory rammer variants.
- Protects the Ram Guide and Lower Assembly: — A functioning bellows seals out dirt, water, and debris from the guide assembly. A cracked or torn bellows allows contamination that accelerates internal wear and leads to costly repairs.
The bellows on a vibratory rammer acts as a flexible protective sleeve between the upper drive housing and the lower compaction shoe assembly. It seals the internal guide mechanism from dust, mud, and moisture that would otherwise infiltrate the ram stroke components during operation. Because the bellows flexes thousands of times per hour under the rammer's impact action, it is subject to progressive fatigue cracking and tearing — making it one of the most routinely replaced wear items on the machine. A failed bellows left unaddressed allows abrasive material into the guide, accelerating wear on internal components and shortening the service life of the entire lower assembly.
Part Details
| Part Number | 5000154700 |
|---|---|
| Old Part Number | 0154700 |
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Red Bellows Ral 3020 |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Vibratory Rammer with 280mm/11 in Shoe | BS60-2 EU | 5000009421 |
| Vibratory Rammer with 280mm/11 in Shoe | BS70-2 EU | 5000009427 |
| Four-cycle Rammer,280mm/11in S hoe | BS60-4s EU | 5000620388, 5000620074, 5000620816, 5200004239 |
| DS 70, 280 mm shoe Red | DS70 | 5000620054, 5000009403 |
| Vibratory Rammer, 280mm/11in s hoe | BS60-4 | 5000620051 |
| BS 60-4s, 280 mm shoe, yellow/red | BS60-4s | 5200000675 |
| Vibratory Rammer | BS600 | 5000009307 |
| 280/11in Shoe, Vibratory Ramme r | BS60-2 | 5200000666 |
| Vibratory Rammer with 280mm/11 in Shoe, red | BS700 | 5000009308 |
| 280/11in Shoe, Vibratory Ramme r | BS70-2 | 5200000676 |
| Diesel Vibratory Rammer, 280mm /11in Shoe, red | DS720 | 5000009309 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
