The Wacker Neuson is a genuine OEM AC 3 Phase Schematic Label designed for the G25, G50, G70, G85, G120, and G125 portable generator series. Sourced directly from Wacker Neuson, this label carries the exact wiring diagram and electrical notation printed to OEM specification, ensuring the information matches the generator's actual electrical layout. It fits across a wide range of skid-mounted, cold weather, and custom-configuration G-series units, making it a practical stock item for fleet operators and service technicians who maintain multiple generator models. When the original label is damaged, faded, or missing, replacing it with part restores a critical on-machine reference that supports safe and accurate servicing.
Key Features
- OEM-Accurate Electrical Diagram: — Printed with the exact 3-phase AC wiring schematic Wacker Neuson specifies for G-series generators, so technicians reference correct connection points every time.
- Direct Replacement Label: — Matches the original label's dimensions and mounting location, adhering directly to the generator enclosure panel without trimming or repositioning.
- Broad G-Series Compatibility: — Verified for G25, G50, G70, G85, G120, and G125 models across skid-mounted, cold weather, and custom configurations — a single part number covering an entire generator family.
- Supports Correct Electrical Servicing: — A legible, accurate schematic on the machine helps service personnel identify phases, terminals, and load connections without consulting a separate manual at every service interval.
- Electrical Safety Reference: — For 3-phase AC power equipment, having the correct wiring diagram physically present on the unit is essential for safe load hookup, fault tracing, and transfer switch operation.
A schematic label on a portable generator serves as a permanent, on-machine wiring reference for the unit's AC electrical system. On 3-phase generators like the Wacker Neuson G-series, it identifies the phase conductors, neutral, ground connections, and output terminal arrangement — information that technicians and electricians rely on when connecting loads, diagnosing faults, or performing output voltage checks. When this label becomes illegible through wear, chemical exposure, or physical damage, it removes a critical safety reference from the machine and should be replaced promptly to maintain safe operating and servicing conditions.
Part Details
| Part Number | 5000155554 |
|---|---|
| Old Part Number | 0155554 |
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | AC 3 Phase Schematic Label |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Mobile Generator (Cold Weather ) | G120 | 5000620291, 5000620290, 5000620292 |
| Skid-mounted Mobile Generator | G25 | 5000009258, 5000009462, 5000009476 |
| Skid-mounted Mobile Generator | G50 | 5000009259, 5000009463, 5000009477 |
| Skid-mounted Mobile Generator | G70 | 5000009260, 5000009464, 5000009478 |
| Skid-mounted Mobile Generator | G85 | 5000009369, 5000009310, 5000009305, 5000009465 |
| Mobile Generator (custom) | G125 | 5000620067, 5000620068, 5000009261 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
