Wacker Neuson 5000177759 Receptacle Wiring Harness LTW20Z3
Wacker Neuson

Wacker Neuson 5000177759 Receptacle Wiring Harness LTW20Z3

$324.66
(No reviews yet) Write a Review
SKU:
5000177759-Wacker Neuson
Adding... The item has been added

The Wacker Neuson Receptacle Wiring Harness LTW20Z3 is a genuine OEM component designed for the LTW20Z3 and LTW20Z3-V series light towers. As a direct factory replacement, part ensures correct connector routing, terminal integrity, and circuit protection for the receptacle circuit on these Isuzu Tier 4i-powered units. This harness is sourced directly from Wacker Neuson, so you get an exact match to the original specification — no guesswork on pin counts, wire gauges, or connector housings. Verified fitment covers standard, cold weather, custom, and skidded configurations across the LTW20Z3 and LTW20Z3-V S model families.

Key Features

  • OEM Electrical Integrity — Manufactured to Wacker Neuson's original wiring specification, maintaining correct conductor gauge, insulation rating, and connector pinout for the receptacle circuit.
  • Drop-In Harness Replacement — Connectors, routing lengths, and mounting points match the original harness exactly, allowing direct installation without splicing or adapter hardware.
  • Broad LTW20Z3 Family Coverage — Confirmed fit across LTW20Z3 and LTW20Z3-V S configurations including standard, cold weather, custom, and skidded variants with Isuzu Tier 4i engines.
  • Protects Receptacle Circuit Function — A damaged or corroded wiring harness can cause intermittent power loss or complete receptacle failure on the light tower; this replacement restores full output circuit reliability.
  • Electrical Safety Compliance — Correct OEM wiring ensures the receptacle circuit operates within rated load parameters, reducing the risk of overheating or arcing at the connector under sustained jobsite use.

The receptacle wiring harness routes and protects the electrical conductors that carry power from the generator to the external power outlet receptacles on the light tower. It provides the correct termination points, insulation, and connector interfaces that allow tools or site equipment to draw power safely from the unit. When this harness degrades — through heat cycling, vibration, moisture ingress, or physical damage — the result can range from intermittent outlet failures to complete loss of receptacle power, or in severe cases, unsafe connector heating. Replacing it with the correct OEM part restores full circuit function and ensures the receptacle operates as intended under continuous load.

Part Details

Part Number5000177759
Old Part Number0177759
BrandWacker Neuson
Part TypeGenuine OEM
DescriptionReceptacle Wiring Harness LTW20Z3

Compatibility & Fitment

Name Model Machine Number
LTW20Z-3, LIGHT TOWER 60HZ, ISUZU TIER 4i LTW20Z3 5000620376, 5000620843, 5200003583, 5200004097, 5200014325, 5200014327, 5200023192, 5200023604, 5200014329
LTW20Z3-V S LIGHT TOWER, COLD WEATHER, T4i LTW20Z3-V S 5200018566, 5200018558, 5200018562, 5200023196, 5100015094, 5100022126
Light Tower LTW20Z3-V 5200012881, 5200012885, 5200012867, 5200022694

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
