The Wacker Neuson Cylinder with Piston is a genuine OEM component designed for DPS and DPU series vibratory plate compactors, including the DPS3050, DPS3060, DPU 2870, DPU 2950, DPU 2960, and DPU 2970 models. Sourced directly from Wacker Neuson, this part is manufactured to the same tolerances and material standards as the original unit installed at the factory. The is a direct-fit replacement that installs exactly like the original, requiring no modification to the host machine. Whether you're restoring a single-direction plate or a reversible compactor to working condition, this assembly delivers the engine performance your crew depends on.
Key Features
- OEM-Grade Bore and Ring Tolerances — Genuine Wacker Neuson manufacture ensures the cylinder bore and piston rings meet the exact clearance specifications required for correct compression and long service life.
- Complete Assembly — Supplied as a matched cylinder and piston unit, simplifying the rebuild process and ensuring correct component pairing straight out of the box.
- Broad DPS and DPU Compatibility — Fits DPS3050, DPS3060, DPU 2870, DPU 2950, DPU 2960, and DPU 2970 vibratory plate compactors — covering both single-direction and reversible plate families.
- Restored Compaction Output — A worn or scored cylinder causes loss of compression, rough running, and reduced centrifugal force output; replacing with 5004103010 restores full plate performance and consistent compaction force.
- Verified OEM Part Number — Ordering by Wacker Neuson part number 5004103010 confirms you're receiving the correct assembly for your specific plate model, eliminating guesswork during a repair.
The cylinder and piston assembly is the core of a vibratory plate compactor's engine, forming the compression chamber where the air-fuel mixture ignites to drive the crankshaft and generate the eccentric force that compacts the ground below. A correctly sealed cylinder maintains the compression ratio the engine was designed around, delivering consistent power to the exciter unit. When the cylinder bore wears, becomes scored, or the piston rings lose their seal, compression drops, the engine loses power, and the plate's compaction force falls below the rated output — leaving soil or aggregate insufficiently compacted and potentially requiring rework.
Part Details
| Part Number | 5004103010 |
|---|---|
| Old Part Number | 4103010 |
| Brand | Wacker Neuson |
| Part Type | Genuine OEM |
| Description | Cylinder with Piston |
Compatibility & Fitment
| Name | Model | Machine Number |
|---|---|---|
| Single Direction Vibratory Pla te, 30kN, 50cm/20in | DPS3050 | 5000006962 |
| Single Direction Vibratory Pla te, 30kN, 60cm/24in | DPS3060 | 5000006963, 5000008422 |
| Reversible Vibratory Plate, 28 kN, 70cm/28in | DPU 2870 | 5000007289 |
| Reversible Vibratory Plate, 29 kN, 70cm/28in | DPU 2970 | 5000007880 |
| Reversible Vibratory Plate, 29 kN, 50cm/20in | DPU 2950 | 5000007881, 5000007884 |
| Vibration Plate DPU 2960 | DPU 2960 | 5000007883 |
Verify Before You Order
Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.
