Wacker Neuson 1000360881 Carry Load Diagram

The Wacker Neuson is a genuine OEM Carry Load Diagram designed for the TH627 telehandler. Sourced directly from Wacker Neuson, this is the exact diagram label specified for the TH627 (418-02) series, ensuring your machine displays the correct load capacity reference information as originally configured. As a genuine OEM component, the meets all original equipment specifications for material, format, and placement.

Key Features

• Genuine OEM Accuracy — Produced by Wacker Neuson to match the exact load ratings and format originally affixed to the TH627, so operators reference correct, machine-specific capacity data.
• Direct Label Replacement — Replaces the worn, damaged, or missing carry load diagram on the TH627 without alteration — mounts in the same location as the original.
• TH627 Telehandler Fitment — Verified for the TH627 (418-02) series telehandler; confirm your machine's model number before ordering.
• Operational Safety Compliance — Load capacity diagrams are a required safety reference on telehandlers; a missing or illegible label leaves operators without critical lift and reach limit guidance, creating an unsafe working condition.
• Preserves Inspection Readiness — Keeps your TH627 compliant with site safety requirements and equipment inspection standards that mandate legible load charts on lifting machines.

A carry load diagram is a safety-critical label mounted in the operator's line of sight on a telehandler. It displays the machine's rated lift capacity at various boom angles and extension lengths, giving operators the information they need to work within safe load limits. When this label is missing, faded, or damaged, operators lose access to essential capacity reference data — increasing the risk of overload, tip-over, or structural damage to the machine.

Part Details

Compatibility & Fitment

Verify Before You Order

Fitment is machine-number and revision-specific; always confirm your model and serial number against the fitment list.

Why Buy From DHS Equipment

Every part is verified against the manufacturer's part number before it ships, so what you order is what arrives. We carry parts from leading OEM brands and our own DHS Quality Parts line of professional aftermarket components. Need help finding the right part? Our team is available to confirm compatibility whenever you need it. Orders are processed fast to keep your jobs on track. We don't just sell parts. We keep you jobsite ready.

Questions? Contact our team at [email protected] or 866-611-9369 — DHS Equipment is here to help you maintain peak performance.
